Toyota Hiace Van,Commuter
1987-08 → 1989-08 · chassis YH5#,6#,LH5#,6# · catalogue 711530 · Europe
Discontinued model
Data version 1989-08
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 81230 — Lamp Assy, Courtesy | ||||
| 81230-95J01 |
Lamp Assy, Courtesy
1987-08 → 1989-08
ended
|
LH5#,6#,YH5#,6# 15S,J,U | — | |
| 81230B — Bulb(FOR COURTESY LAMP) | ||||
| 99132-12050 note |
Bulb(FOR COURTESY LAMP)
1987-08 → 1989-08
ended
|
LH5#,6#,YH5#,6# 15S,J,U | — | |
| 81231 — Lens, Courtesy Lamp | ||||
| 81271-89110 |
Lens, Courtesy Lamp
1987-08 → 1989-08
ended
|
LH5#,6#,YH5#,6# 15S,J,U | — | |
| 81234 — Gasket, Courtesy Lamp | ||||
| 81234-95J01 note |
Gasket, Courtesy Lamp
1987-08 → 1989-08
ended
|
LH5#,6#,YH5#,6# 15S,J,U | — | |
| 81272-89110 note |
Gasket, Courtesy Lamp
1987-08 → 1989-08
ended
|
LH5#,6#,YH5#,6# 15S,J,U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
