Toyota Hiace Van,Commuter
1989-08 → 1995-08 · chassis LH10#,11#,RZH10#,11# · catalogue 711540 · Europe
Discontinued model
Data version 1995-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 44730 — Valve Assy, Vacuum Check(FOR BRAKE) | ||||
| 44730-24020 |
Valve Assy, Vacuum Check(FOR BRAKE)
1989-08 → 1992-05
ended
|
RZH10#,11# | — | |
| 44730-24020 |
Valve Assy, Vacuum Check(FOR BRAKE)
1992-05 → 1995-08
ended
|
RZH10#,11# | — | |
| 44730-60050 |
Valve Assy, Vacuum Check(FOR BRAKE)
1989-08 → 1995-08
ended
|
LH10#,11# | — | |
| 44730C — Clip(FOR VACUUM HOSE) | ||||
| 90467-16002 |
Clip(FOR VACUUM HOSE)
1992-05 → 1993-08
ended
|
LH10#,11#,RZH10#,11# | — | |
| 90467-16002 note |
Clip(FOR VACUUM HOSE)
1993-08 → 1995-08
ended
|
LH10#,11#,RZH10#,11# | — | |
| 90467-16002 |
Clip(FOR VACUUM HOSE)
1993-08 → 1995-08
ended
|
RZH113 LHD;LH10#,11#,RZH10#,119 | — | |
| 90467-16002 |
Clip(FOR VACUUM HOSE)
1993-08 → 1995-08
ended
|
RZH113 RHD | — | |
| 90467-16002 |
Clip(FOR VACUUM HOSE)
1989-08 → 1992-05
ended
|
LH10#,11#,RZH10#,11# | — | |
| 44730F — Union, Vacuum Hose(FOR MANIFOLD SIDE) | ||||
| 90404-51031 |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1989-08 → 1992-05
ended
|
RZH10#,11# | — | |
| 90404-51031 |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1992-05 → 1995-08
ended
|
RZH10#,11# | — | |
| 90405-09134 note |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1994-01 → 1994-05
ended
|
LH112 DX | — | |
| 90405-09134 |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1989-08 → 1995-08
ended
|
LH108,118 | — | |
| 90405-09135 |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1989-08 → 1995-08
ended
|
LH102,112 | — | |
| 44758 — Bracket, Vacuum Check Valve | ||||
| 44758-26060 |
Bracket, Vacuum Check Valve
1989-08 → 1995-08
ended
|
RZH112,113 RHD | — | |
| 44758-26070 |
Bracket, Vacuum Check Valve
1989-08 → 1992-05
ended
|
RZH10#,11# LHD | — | |
| 44758-26070 |
Bracket, Vacuum Check Valve
1992-05 → 1995-08
ended
|
RZH10#,11# LHD | — | |
| 44761 — Tube, Intake Manifold OR Vacuum Pump TO Connector | ||||
| 44761-26150 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1989-08 → 1993-08
ended
|
LH102,112 RHD | — | |
| 44761-26160 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1989-08 → 1993-08
ended
|
LH10#,11# LHD | — | |
| 44761-26170 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1989-08 → 1993-08
ended
|
RZH112 4D 03S | — | |
| 44761-26180 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1989-08 → 1992-05
ended
|
RZH10#,11# LHD | — | |
| 44761-26180 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1992-05 → 1993-08
ended
|
RZH10#,11# LHD | — | |
| 44761-26230 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1993-08 → 1995-08
ended
|
RZH113 RHD | — | |
| 44761-26240 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1993-08 → 1995-08
ended
|
LH102,112 RHD | — | |
| 44761-26250 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1993-08 → 1995-08
ended
|
RZH10#,11# LHD | — | |
| 44761-26260 |
Tube, Intake Manifold OR Vacuum Pump TO Connector
1993-08 → 1995-08
ended
|
LH10#,11# LHD | — | |
| 44764G — Tube, Connector TO Brake Booster | ||||
| 44764-26070 |
Tube, Connector TO Brake Booster
1989-08 → 1995-08
ended
|
LH102,112,RZH112,113 RHD | — | |
| 44764-26080 |
Tube, Connector TO Brake Booster
1989-08 → 1992-05
ended
|
LH10#,11#,RZH10#,11# LHD | — | |
| 44764-26080 |
Tube, Connector TO Brake Booster
1992-05 → 1995-08
ended
|
LH10#,11#,RZH10#,11# LHD | — | |
| 44771 — Hose, Vacuum Tube Connector | ||||
| 44771-26090 |
Hose, Vacuum Tube Connector
1989-08 → 1995-08
ended
|
RZH112,113 RHD | — | |
| 44771-26100 |
Hose, Vacuum Tube Connector
1989-08 → 1992-05
ended
|
RZH10#,11# LHD | — | |
| 44771-26100 |
Hose, Vacuum Tube Connector
1992-05 → 1995-08
ended
|
RZH10#,11# LHD | — | |
| 44771-26110 |
Hose, Vacuum Tube Connector
1989-08 → 1995-08
ended
|
LH102,112 RHD | — | |
| 44771-26120 |
Hose, Vacuum Tube Connector
1989-08 → 1995-08
ended
|
LH10#,11# LHD | — | |
| 44772 — Hose, Check Valve TO Connector Tube | ||||
| 44772-26110 |
Hose, Check Valve TO Connector Tube
1989-08 → 1995-08
ended
|
LH102,112 RHD | — | |
| 44772-26120 |
Hose, Check Valve TO Connector Tube
1989-08 → 1995-08
ended
|
LH10#,11# LHD | — | |
| 44772-26130 |
Hose, Check Valve TO Connector Tube
1989-08 → 1995-08
ended
|
RZH112,113 RHD | — | |
| 44772-26140 |
Hose, Check Valve TO Connector Tube
1989-08 → 1992-05
ended
|
RZH10#,11# LHD | — | |
| 44772-26140 |
Hose, Check Valve TO Connector Tube
1992-05 → 1995-08
ended
|
RZH10#,11# LHD | — | |
| 44774 — Hose, Union TO Connector Tube | ||||
| 44774-26180 |
Hose, Union TO Connector Tube
1989-08 → 1992-05
ended
|
RZH102,112 | — | |
| 44774-26180 |
Hose, Union TO Connector Tube
1992-05 → 1995-08
ended
|
RZH102,112 | — | |
| 44774-26190 |
Hose, Union TO Connector Tube
1989-08 → 1995-08
ended
|
RZH103,109,113,115,119 | — | |
| 44774-26200 |
Hose, Union TO Connector Tube
1989-08 → 1995-08
ended
|
LH102,112 | — | |
| 44774-26210 |
Hose, Union TO Connector Tube
1989-08 → 1995-08
ended
|
LH108,118 | — | |
| 44776 — Hose, Brake Booster | ||||
| 44776-26020 |
Hose, Brake Booster
1989-08 → 1992-05
ended
|
RZH10#,11# | — | |
| 44776-26020 |
Hose, Brake Booster
1992-05 → 1995-08
ended
|
RZH10#,11# | — | |
| 44776-26030 |
Hose, Brake Booster
1989-08 → 1995-08
ended
|
LH10#,11# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
