Toyota Lexus LM500H/350H

2023-06 → present · chassis AAWH1#,TAWH15 · catalogue 714320 · Europe

Supported model Data version 2023-11

Armrest & Visor

49 part groups · 2 illustrations

PNC	Description
55633G	Support, Cup Holder, NO.1
58911K	Panel, Box Side, NO.1
58912G	Panel, Box Side, NO.2
58959R	Cushion, Console Compartment Door
589A0C	Table Assy, Quarter Console, RH
589A0D	Table Assy, Quarter Console, LH
66990Z	Holder Assy, Cup, RH
66J90	Holder Assy, Cup, LH
72083E	Clamp, Wiring Harness
72083F	Clip
72083G	Housing, Connector Male
72083H	Housing, Connector Female, NO.1
72083M	Pad Sub-assy, Quarter Armrest, RH
72084E	Pad Sub-assy, Quarter Armrest, LH
74210	Armrest Assy, Front, RH
74220	Armrest Assy, Front, LH
74231C	Panel, Front Door Armrest Base, Upper Driver Side
74232C	Panel, Front Door Armrest Base, Upper Passenger Side
74261C	Cover, Quarter Armrest, RH
74262C	Cover, Quarter Armrest, LH
74271B	Panel, Quarter Armrest Base, RH
74272B	Panel, Quarter Armrest Base, LH
74310	Visor Assy, RH
74317	Cover, Visor Bracket, RH
74318	Cover, Visor Bracket, LH
74320	Visor Assy, LH
74348B	Holder, Visor, RH
74348C	Holder, Visor, LH
74610A	Grip Sub-assy, Assist
74610B	Grip Assy, Assist, NO.2 RH
74610K	Grip Assy, Assist, NO.2 LH
74611B	Grip, Assist
74611C	Cover, Assist Grip, LH
74611F	Grip, Assist, NO.1
74611G	Grip, Assist, NO.2
74612	Cover, Assist Grip
74612C	Cover, Assist Grip, RH
74612F	Cover, Assist Grip
74613	Plug, Assist Grip
74617A	Plug, Assist Grip
74617C	Plug, Assist Grip
74617F	Plug, Assist Grip
74617G	Plug, Assist Grip, NO.3 RH
74617P	Plug, Assist Grip, NO.3 LH
74617V	Plug, Assist Grip
74617W	Plug, Assist Grip
74617X	Plug, Assist Grip
74680B	Grip Assy, Pillar Assist, RH
74680C	Grip Assy, Pillar Assist, LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
