Toyota Dyna

2001-07 → 2021-11 · chassis KDY22#,23#,25#,26#,LY2## · catalogue 731270 · Europe

Discontinued model Data version 2022-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Panel & Back Panel

30 part groups · 3 illustrations

Illustrations

Figure 611382F 611382F 2001-07 → — Figure 611453G 611453G 2001-08 → 2015-02 Figure 611454E 611454E 2001-08 → 2015-02

Part groups

PNCDescription
53764A Bracket, Air Cleaner Inlet, NO.1
53765B Bracket, Air Cleaner Inlet, NO.2
53773B Bracket, Air Cleaner Inlet, NO.2
58930B Band Assy, Engine Service Hole Cover Support
58935A Bracket, Engine Service Hole Cover Support Band
61262C Channel, Roof Drip, Rear
61267F Channel, Roof Drip Side, Rear RH
61268C Channel, Roof Drip Side, Rear LH
63031B Strength Sub-assy, Roof Panel, Center RH NO.1
63103A Reinforcement Sub-assy, Roof Panel
63111 Panel, Roof
63123C Reinforcement, Roof Panel
63129A Cushion, Roof Reinforcement
63132 Panel, Windshield Header, Inner
63141G Reinforcement, Roof Panel, NO.1
63142 Reinforcement, Roof Panel, NO.2
63332D Pad, Sun Roof Headlining
63358D Bracket, Roof Silencer, Rear
64111A Panel, Back
64115B Reinforcement, Back Panel
64117A Reinforcement, Cab Back, Lower
64122A Baffle, Dust Rear Body
64145D Bracket, Rear Seatback Set
64145E Bracket, Rear Seatback Set
64149B Retainer, Back Panel Headrest
64211B Panel, Upper Rear Cab, Outer
64225A Hanger, Rear Seat Cushion Support
64811 Glass, Back Window
64831 Weatherstrip, Back Window Glass
64832 Key, Back Window Weatherstrip
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
