Toyota DYNA200
1995-05 → 2003-12 · chassis BU10#,11#,14#,21#,22#,YU210,RZU100 · catalogue 751260 · Europe
Discontinued model
Data version 2004-06
Disc Wheel & Wheel Cap
13 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 42601 | Wheel, Disc |
| 42601A | Wheel, Disc (FOR SPARE) |
| 42601C | Nut, Hub (FOR AXLE) |
| 42611G | Valve (FOR TUBELESS TIRE) |
| 42611H | Extension, Valve |
| 42611J | Valve (FOR TUBELESS TIRE SPARE) |
| 42611Q | Clip (FOR TUBE) |
| 42611T | Washer (FOR TUBE) |
| 42611U | Cap, Tire Valve |
| 42613A | Ring, Disc Wheel Side |
| 42621 | Cap, Wheel |
| 42652 | Tire |
| 42652A | Tire (FOR SPARE) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
