Factory parts data · Europe

Toyota Dyna

1999-07 → 2002-12 · chassis XZU30#,320,330,34# · catalogue 751270 · Europe

Discontinued model Data version 2003-08

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Fuel Filter

10 part groups · 2 illustrations

Illustrations

Figure 230158A

230158A 1999-07 → —

Figure 230178A

230178A 2000-10 → —

Part groups

PNC	Description
23301A	Cap Assy, Fuel Filter
23303	Element Sub-assy, Fuel Filter
23322	Plug, Drain(FOR FUEL FILTER)
23322A	Ring, O(FOR DRAIN PLUG)
23338	Gasket(FOR WARNING SWITCH)
23389	Clamp, Fuel Filter
23910B	Heater Assy, Fuel
23921	Support, Fuel Filter
23925	Stay, Fuel Filter Support
84461B	Switch, Level Warning

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
