Toyota Dyna
1999-07 → 2002-12 · chassis XZU30#,320,330,34# · catalogue 751270 · Europe
Discontinued model
Data version 2003-08
Shift Lever & Retainer
31 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 33503F | Lever Sub-assy, Shift(FOR FLOOR SHIFT) |
| 33504F | Knob Sub-assy, Shift Lever |
| 33506F | Retainer Sub-assy, Control Shift Lever (FOR FLOOR SHIFT) |
| 33506H | Bush (FOR SHIFT LEVER RETAINER) |
| 33506Q | Grommet, NO.1(FOR CONTROL SHIFT LEVER RETAINER) |
| 33509 | Crank Sub-assy, Selecting Bell, NO.1 |
| 33534 | Bellcrank, Selecting |
| 33534C | Bush (FOR SELECTING BELLCRANK NO.1) |
| 33539 | Cushion, Shift Lever Anti-rattle |
| 33548F | Bush, NO.1, Shift Lever (FOR FLOOR SHIFT) |
| 33586A | Stopper, Control Lever (FOR FLOOR SHIFT) |
| 33602B | Bushing (FOR SELECT LEVER) |
| 33602D | Collar (FOR SELECT LEVER) |
| 33602E | Spring, Torsion (FOR SELECT LEVER) |
| 33602F | Lever Sub-assy, Select (FOR FLOOR SHIFT) |
| 33608 | Support Sub-assy, Selecting Bellcrank |
| 33709F | Shaft Sub-assy, Cross, NO.1 (FOR FLOOR SHIFT) |
| 33769A | Spring, Cross Shaft End |
| 33820J | Clip(FOR TRANSMISSION CONTROL CABLE) |
| 33821 | Cable Transmission Control Shift (FOR FLOOR SHIFT) |
| 33822 | Cable Transmission Control Select (FOR FLOOR SHIFT) |
| 33823 | Bracket, Transmission Control Cable, NO.1 |
| 33826A | Bracket, Transmission Control Cable, NO.2 |
| 33826B | Bracket, Transmission Control Cable, NO.3 |
| 33826C | Bracket, Transmission Control Cable, NO.4 |
| 33826D | Bracket, Transmission Control Cable, NO.5 |
| 33826E | Bracket, Transmission Control Cable, NO.6 |
| 33826F | Bracket, Transmission Control Cable, NO.7 |
| 33826R | Bracket, Transmission Control Cable, NO.8 |
| 33829B | Clamp, Transmission Control Cable |
| 33840F | Rod Assy, Gear Shifting, NO.3 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
