Toyota Dyna
1999-07 → 2002-12 · chassis XZU30#,320,330,34# · catalogue 751270 · Europe
Discontinued model
Data version 2003-08
Front Panel & Windshield Glass
29 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 53145F | Clip, Radiator Grille Garnish |
| 53801J | Panel Sub-assy, Front Side, RH |
| 53802J | Panel Sub-assy, Front Side, LH |
| 53821A | Protector, Front Side Panel, NO.1 RH |
| 53822A | Protector, Front Side Panel, NO.1 LH |
| 53928A | Garnish, Front Panel, Center |
| 55078 | Cover Sub-assy, Front Panel |
| 55145G | Clip, Radiator Grille Garnish |
| 55211B | Silencer, Front Panel |
| 55212A | Silencer, Front Panel, Lower |
| 55700 | Panel Assy, Front |
| 55711A | Panel, Front, Lower |
| 55717F | Extension, Front Panel Reinforcement, RH |
| 55718E | Extension, Front Panel Reinforcement, LH |
| 55738B | Protector, Front Panel Cover, NO.1 |
| 55739B | Protector, Front Panel Cover, NO.2 |
| 55785C | Pad, Front Panel Cover |
| 56111 | Glass, Windshield |
| 56121 | Weatherstrip, Windshield |
| 63273S | Retainer, Roof Window Hinge |
| 63787B | Pad, Roof Air Deflector, NO.1 |
| 74306A | Support Sub-assy, Front Visor |
| 74310D | Visor Assy |
| 74321B | Visor, Front |
| 74325B | Support, Front Visor, RH |
| 74326B | Support, Front Visor, LH |
| 74327A | Pad, Front Visor |
| 74328A | Pad, Front Visor, NO.2 |
| 74328B | Pad, Front Visor, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
