Toyota DYNA200
1988-08 → 1995-05 · chassis BU7#,8#,9# · catalogue 751550 · Europe
Discontinued model
Data version 1995-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82001 — Cable, Bond, NO.1 | ||||
| 90980-07181 note |
Cable, Bond, NO.1
1988-08 → 1988-12
ended
|
BU76,88,96 | — | |
| 90980-07194 note |
Cable, Bond, NO.1
1988-08 → 1995-05
ended
|
BU84,89 | — | |
| 90980-07227 note |
Cable, Bond, NO.1
1988-08 → 1989-10
ended
|
BU76,8#,96 | — | |
| 90980-07291 note |
Cable, Bond, NO.1
1988-08 → 1993-11
ended
|
BU7#,8#,9# | — | |
| 90980-07291 note |
Cable, Bond, NO.1
1993-11 → 1995-05
ended
|
BU79,89,92 | — | |
| 90980-07313 note |
Cable, Bond, NO.1
1988-12 → 1993-11
ended
|
BU7#,88,9# | — | |
| 90980-07313 note |
Cable, Bond, NO.1
1993-11 → 1995-05
ended
|
BU79,92 | — | |
| 90980-07317 note |
Cable, Bond, NO.1
1989-10 → 1993-11
ended
|
BU7#,8#,9# | — | |
| 90980-07317 note |
Cable, Bond, NO.1
1993-11 → 1995-05
ended
|
BU79,89,92 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
