Toyota Dyna
1977-08 → 1984-11 · chassis RU2#,30,JU20,BU2#,3#,40,HU30,40,50,WU40 · catalogue 752220 · Europe
Discontinued model
Data version 1985-03
Seat & Seat Track
52 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 70011 | Cushion Assy, NO.1 Seat |
| 70012 | Back Assy, NO.1 Seat |
| 70012B | Band, Engine Service Hole Cover Support |
| 70013 | Cover Assy, NO.1 Seat Cushion |
| 70014 | Cover Assy, NO.1 Seatback |
| 70021 | Cushion Assy, NO.2 Seat |
| 70022 | Back Assy, NO.2 Seat |
| 70023 | Cover Assy, NO.2 Seat Cushion |
| 70024 | Cover Assy, NO.2 Seatback |
| 70031 | Cushion Assy, NO.3 Seat |
| 70032 | Back Assy, NO.3 Seat |
| 70033 | Cover Assy, NO.3 Seat Cushion |
| 70034 | Cover Assy, NO.3 Seatback |
| 70041 | Cushion Assy, NO.4 Seat |
| 70042 | Back Assy, NO.4 Seat |
| 70043 | Cover Assy, NO.4 Seat Cushion |
| 70044 | Cover Assy, NO.4 Seatback |
| 70051 | Cushion Assy, NO.5 Seat |
| 70052 | Back Assy, NO.5 Seat |
| 70053 | Cover Assy, NO.5 Seat Cushion |
| 70054 | Cover Assy, NO.5 Seatback |
| 70061 | Cushion Assy, NO.6 Seat |
| 70062 | Back Assy, NO.6 Seat |
| 70063 | Cover Assy, NO.6 Seat Cushion |
| 70064 | Cover Assy, NO.6 Seatback |
| 71203 | Hinge Sub-assy, Passenger Seat, RH |
| 71204 | Hinge Sub-assy, Passenger Seat, LH |
| 71218A | Spring, Passenger Seat Lock |
| 71237 | Bracket, Rear Seat |
| 71242 | Hinge, Passenger Seatback, RH |
| 71243 | Hinge, Passenger Seatback, LH |
| 71307 | Hinge Sub-assy, Driver Seat, RH |
| 71308 | Hinge Sub-assy, Driver Seat, LH |
| 71316A | Spring, Torsion, NO.1 |
| 71316B | Spring, Torsion, NO.2 |
| 71405 | Post Sub-assy, Rear Seat, Front |
| 71407 | Post Sub-assy, Rear Seat, Rear |
| 71419 | Cushion (FOR REAR SEAT LEG) |
| 71470 | Frame Assy, Rear Seat Cushion, Front |
| 71470A | Frame Assy, Rear Seat Cushion, Rear |
| 71472 | Bracket, Rear Seat Leg Support |
| 71484A | Spring, Rear Seat Leg |
| 71609 | Band Sub-assy, Rear Side Seat |
| 71812 | Clip (FOR FRONT SEAT CUSHION COVER) |
| 71901 | Catch Sub-assy, Seat Cushion, Rear |
| 71922 | Hook, Rear Seat |
| 71924 | Pin, Rear Seat |
| 72110S | Track Assy, RH Seat, Outer (FOR SEPARATE SEAT) |
| 72120S | Track Assy, LH Seat, Outer (FOR SEPARATE SEAT) |
| 72317 | Grommet, Sub Seat Cushion |
| 72510 | Adjuster Assy, Reclining Seatback, RH |
| 72520 | Adjuster Assy, Reclining Seatback, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
