Toyota Dyna
2011-07 → present · chassis WU700,710,720,XZU710,720,730 · catalogue 771250 · Europe
Supported model
Data version 2019-11
Rear Disc Brake Caliper & Dust Cover
17 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 04466 | Pad Kit, Disc Brake, Rear |
| 04479A | Cylinder Kit, Disc Brake, Rear |
| 04946 | Shim Kit, Anti Squeal(FOR REAR DISC BRAKE) |
| 04948 | Fitting Kit, Disc Brake, Rear |
| 31478C | Cap, Bleeder Plug(FOR REAR DISC BRAKE) |
| 47547C | Plug, Bleeder(FOR REAR DISC BRAKE) |
| 47715C | Pin, Cylinder Slide(FOR REAR DISC BRAKE) |
| 47715F | Pin, Cylinder Slide, NO.2(FOR REAR DISC BRAKE) |
| 47721C | Mounting, Rear Disc Brake Cylinder, RH |
| 47721D | Bolt(FOR REAR DISC BRAKE CYLINDER MOUTING) |
| 47722A | Mounting, Rear Disc Brake Cylinder, LH |
| 47731B | Piston, Rear Disc Brake |
| 47775D | Boot, Bush Dust(FOR REAR DISC BRAKE) |
| 47803 | Cover Sub-assy, Disc Brake Dust, Rear RH |
| 47804 | Cover Sub-assy, Disc Brake Dust, Rear LH |
| 47830 | Cylinder Assy, Disc Brake, Rear RH |
| 47850 | Cylinder Assy, Disc Brake, Rear LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
