Toyota Land Cruiser

1980-08 → 1986-04 · chassis BJ4#,HJ47,FJ4# · catalogue 781210 · Europe

Discontinued model Data version 1987-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Cab Mounting & Body Mounting

29 part groups · 2 illustrations

Illustrations

Figure MBB511B MBB511B 1980-08 → — Figure MBD522B MBD522B 1980-08 → —

Part groups

PNCDescription
52032 Shim Sub-assy, Cowl Body Mounting
52034 Plate Sub-assy, Deck Mounting Shim
52201 Cushion Assy, Body Mounting, Upper
52208 Shim Sub-assy, Body Mounting
52211 Cushion, Body Mounting, NO.1 Upper
52211B Bolt(FOR BODY MOUNTING NO.1 CUSHION)
52211C Spacer(FOR BODY MOUNTING NO.1 CUSHION)
52212 Spacer, Body Mounting
52214 Cushion, Body Mount, NO.1 Lower
52218 Holder, Body Mount Bolt Spacer, NO.1
52221 Cushion, Body Mount, NO.2 Upper
52221B Bolt(FOR BODY MOUNT NO.2 CUSHION)
52221C Spacer(FOR BODY MOUNT NO.2 CUSHION)
52224 Cushion, Body Mount, NO.2 Lower
52231 Cushion, Body Mount, NO.3 Upper
52231B Bolt(FOR BODY MOUNT NO.3 CUSHION)
52231C Spacer(FOR BODY MOUNT NO.3 CUSHION)
52234 Cushion, Body Mount, NO.3 Lower
52241 Cushion, Body Mount, NO.4 Upper
52241B Bolt(FOR BODY MOUNT NO.4 CUSHION)
52241C Spacer(FOR BODY MOUNT NO.4 CUSHION)
52244 Cushion, Body Mount, NO.4 Lower
52251 Cushion, Body Mount, NO.5 Upper
52251B Bolt(FOR BODY MOUNT NO.5 CUSHION)
52251C Spacer(FOR BODY MOUNT NO.5 CUSHION)
52254 Cushion, Body Mount, NO.5 Lower
52258 Holder, Body Mount Bolt Spacer, NO.5
52321 Plate, Body Mounting Shim
66443 Shim, Mounting, NO.3
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
