Toyota Land Cruiser

1980-08 → 1986-04 · chassis BJ4#,HJ47,FJ4# · catalogue 781210 · Europe

Discontinued model Data version 1987-01

Side Member

41 part groups · 3 illustrations

PNC	Description
55191	Bolt, Safety Strap Ring
58077	Cover Sub-assy, Jack Box Hole
58786A	Stopper, Jack Box Hole Cover
58787A	Packing, Jack Box Hole Cover
61009	Flange Sub-assy,Rear Side Service Hole Cover Set
61067B	Bracket Sub-assy, Seat Belt Retractor, Rear RH
61068B	Bracket Sub-assy, Seat Belt Retractor, Rear LH
61101	Panel Sub-assy, Cowl Side, RH
61102	Panel Sub-assy, Cowl Side, LH
61105	Pillar Sub-assy, Front Body Lower Outer, RH
61106	Pillar Sub-assy, Front Body Lower Outer, LH
61170	Bracket Assy, Safety Strap, RH
61180	Bracket Assy, Safety Strap, LH
61190	Strap Assy, Safety
61320	Panel, Rear Body Front Side, RH
61330	Panel, Rear Body Front Side, LH
61331	Gusset, Rear Body Front Side, Rear RH
61510	Panel Assy, Rear Upper Side, RH
61510A	Grommet, Safety Belt Anchorage Nut
61520	Panel Assy, Rear Upper Side,LH
61539	Packing, Rear Upper Side Panel Set
61549	Cover, Room Side Lamp Hole
61603A	Apron, Rear Fender, RH
61603B	Grommet, Seat Belt Anchor
61604A	Apron, Rear Fender, LH
61610	Panel Assy, Rear Body Side, RH
61610A	Support, Rear Side Panel
61620	Panel Assy, Rear Body Side, LH
61683	Packing, Rear Body Rear Side Service Hole Cover
61687A	Weatherstrip, Rear Body Rear Side, RH
61688A	Weatherstrip, Rear Body Rear Side, LH
61691	Plate, Rear Fender Under Guard
61698B	Cover, Rear Body Side Service Hole
61704A	Door Sub-assy, Tool Box
61704B	Cable Sub-assy(FOR TOOL BOX DOOR)
61704C	Knob(FOR TOOL BOX DOOR)
61704D	Packing(FOR TOOL BOX DOOR)
61704E	Spring(FOR TOOL BOX DOOR)
64931	Bracket, Band, NO.1
64932	Bracket, Band, NO.2
65839	Spacer, Front Side Panel Pillar

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
