Toyota Land Cruiser

1980-08 → 1986-04 · chassis BJ4#,HJ47,FJ4# · catalogue 781210 · Europe

Discontinued model Data version 1987-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Tool Box & License Plate Bracket

17 part groups · 2 illustrations

Illustrations

Figure MBB609B MBB609B 1980-08 → — Figure MBD104A MBD104A 1980-08 → —

Part groups

PNCDescription
52177 Handle, Starting OR Spare Wheel Carrier
58706 Bracket Sub-assy, Jack Handle
58709A Carrier Sub-assy, Jack
58760 Holder Assy, Starting Handle
58762 Holder, Starting Handle
75102 Bracket Sub-assy, Rear License Plate
75111 Bracket, Front License Plate
75123 Bracket, License Plate
75126 Stay, Rear License Plate Bracket, Lower
75135 Bracket, Combination Rear Lamp, RH
75136 Bracket, Combination Rear Lamp, LH
75202 Rest Sub-assy, Jack
75214 Clamp, Tool Bag Band
75216 Bracket, Tool Bag Band
75217 Band, Tool Bag
75221 Bracket, Tool Box
75242 Cushion, Jack Seat
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
