Toyota Land Cruiser
1980-08 → 1986-04 · chassis BJ4#,HJ47,FJ4# · catalogue 781210 · Europe
Discontinued model
Data version 1987-01
Wiring & Clamp
33 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 82001 | Cable, Bond, NO.1 |
| 82002 | Cable, Battery TO Magnet Switch |
| 82002A | Cable, Magnet Switch TO Winch |
| 82002B | Cable, Winch TO Ground |
| 82024 | Wire Sub-assy, Fog Lamp Feed |
| 82046A | Wire Sub-assy, Body Ground, NO.1 |
| 82051 | Harness Assy, Fuel Control |
| 82121 | Wire, Engine |
| 82132 | Wire, Cowl, NO.2 |
| 82210 | Harness Assy, Wiring Cowl TO Headlamp, NO.1 |
| 82210C | Fusible Link |
| 82215 | Wire, Parking Brake Lamp Switch |
| 82220 | Harness Assy, Wiring Cowl |
| 82221 | Wire, Oil Pressure Switch |
| 82222 | Wire, Heat Gage |
| 82271 | Wiring, Hazard Warning Switch |
| 82275 | Wire, Alternator |
| 82291 | Wiring, TO Solenoid |
| 82310 | Wiring Assy, TO Back UP Lamp Switch |
| 82330 | Wiring Assy, TO Vacuum Warning Switch |
| 82345 | Diode |
| 82351A | Wire, Courtesy Lamp Switch (FOR FRONT OR REAR DOOR) |
| 82370 | Wire Assy, Wiper Switch TO Wiper |
| 82374 | Wire, Washer |
| 82380 | Wiring Assy, Trailer Socket |
| 82412 | Wire, Fuel Gage |
| 82415A | Wire, Level Warning |
| 82420 | Wiring Assy, Chassis |
| 82470 | Wire Assy, License Lamp Feed |
| 82510 | Wiring Assy, Roof |
| 82670 | Block Assy, Junction, NO.1 |
| 82672 | Cover, Junktion Block |
| 82823 | Cap, Terminal, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
