Toyota Land Cruiser Prado
2024-01 → present · chassis GDJ25#,TJA250,TRJ250 · catalogue 781290 · Europe
Supported model
Data version 2024-07
Vacuum Piping
37 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 17341P | Hose, Air |
| 17342L | Hose, Air, NO.2 |
| 17578B | Clamp, Pipe |
| 17650G | Valve, Duty Vacuum Switching |
| 17696 | Bracket, Gas Filter |
| 23265C | Filter, Gas |
| 23287A | Hose, Vacuum(FOR VACUUM TRANSMITTING VALVE) |
| 23820 | Hose Assy, Fuel Vapor Feed |
| 23826 | Hose, Fuel Vapor Feed, NO.1 |
| 23826A | Clip(FOR FUEL VAPOR FEED HOSE, NO.1) |
| 23827A | Hose, Fuel Vapor Feed, NO.2 |
| 23827B | Clip(FOR FUEL VAPOR FEED HOSE, NO.2) |
| 23828 | Hose, Fuel Vapor Feed, NO.3 |
| 23829B | Clip(FOR FUEL VAPOR FEED HOSE) |
| 23831 | Connector, Fuel Vapor Feed, NO.1 |
| 23841G | Clamp, Fuel Hose |
| 25706 | Pipe Sub-assy, Vacuum Transmitting, NO.1 |
| 25707 | Pipe Sub-assy, Vacuum Transmitting, NO.2 |
| 25708 | Pipe Sub-assy, Vacuum Transmitting, NO.3 |
| 25709E | Pipe Sub-assy, Vacuum Transmitting, NO.4 |
| 25733A | Pipe, Vacuum, NO.1 |
| 25734 | Pipe, Vacuum, NO.2 |
| 25760 | Hose Assy, Vacuum Transmitting |
| 25760A | Hose Assy, Vacuum Transmitting |
| 25761B | Hose, Vaccum Transmitting, NO.1 |
| 25770 | Hose Assy, Vacuum Transmitting, NO.2 |
| 25771B | Hose, Vaccum Transmitting, NO.2 |
| 25780 | Hose Assy, Vacuum Transmitting, NO.3 |
| 25781A | Hose, Vacuum Transmitting, NO.3 |
| 25790 | Hose Assy, Vacuum Transmitting, NO.4 |
| 25804 | Valve Set, Vacuum Control |
| 25819 | Valve Assy, Vacuum Regulating |
| 25860 | Valve Assy, Vacuum Switching, NO.1 |
| 25861 | Bracket, Vacuum Switching Valve |
| 25894 | Filter, NO.1 |
| 48889 | Clamp, Stabilizer Control Tube |
| 77196B | Clamp, Evaporation Vent Tube, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
