Toyota Land Cruiser Prado
2024-01 → present · chassis GDJ25#,TJA250,TRJ250 · catalogue 781290 · Europe
Supported model
Data version 2024-07
Rear Seat & Seat Track
169 part groups · 20 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 66310P | Hook Assy, Rope |
| 71015C | Frame Sub-assy, NO.1 Seat Cushion, RH |
| 71016B | Frame Sub-assy, NO.1 Seat Cushion, LH |
| 71033H | Leg Sub-assy, Rear Seat Cushion |
| 71075F | Cover Sub-assy, NO.1 Seat Cushion, RH |
| 71075H | Clip(FOR REAR SEAT) |
| 71076F | Cover Sub-assy, NO.1 Seat Cushion, LH |
| 71077 | Cover Sub-assy, Rear NO.1 Seatback, RH |
| 71078A | Cover Sub-assy, Rear NO.1 Seatback, LH |
| 71301G | Hinge Sub-assy, Rear NO.1 Seat, RH(FOR RH SEAT) |
| 71301H | Hinge Sub-assy, Rear NO.1 Seat, RH(FOR LH SEAT) |
| 71302C | Hinge Sub-assy, Rear NO.1 Seat, LH(FOR RH SEAT) |
| 71302G | Hinge Sub-assy, Rear NO.1 Seat, LH(FOR LH SEAT) |
| 71370H | Holder Assy, Rear Seat Cushion |
| 71430E | Clip |
| 71461H | Spring, Rear Seat Cushion |
| 71485E | Cover, Rear Seat Hinge |
| 71486F | Cover, Rear Seat Hinge, LH |
| 71611H | Pad, Rear NO.1 Seat Cushion, RH |
| 71612G | Pad, Rear NO.1 Seat Cushion, LH |
| 71652A | Pad, Rear NO.1 Seatback, LH |
| 71691N | Cover, Rear Seat Cushion Hinge, Upper RH NO.1 |
| 71691P | Cover, Rear Seat Cushion Hinge, Upper RH NO.2 |
| 71691W | Cover, Rear Seat Cushion Hinge, NO.1 |
| 71691X | Cover, Rear Seat Cushion Hinge, NO.2 |
| 71692L | Cover, Rear Seat Cushion Hinge, Upper LH NO.1 |
| 71692M | Cover, Rear Seat Cushion Hinge, Upper LH NO.2 |
| 71692N | Cover, Rear Seat Cushion Hinge, NO.3 |
| 71692P | Cover, Rear Seat Cushion Hinge, NO.4 |
| 71693F | Cover, Rear NO.2 Seat Cushion Hinge, Lower RH NO.1 |
| 71693G | Cover, Rear NO.2 Seat Cushion Hinge, Lower RH NO.2 |
| 71694A | Cover, Rear NO.2 Seat Cushion Hinge, Lower LH NO.1 |
| 71694B | Cover, Rear NO.2 Seat Cushion Hinge, Lower LH NO.2 |
| 71695S | Protector, Rear Seat, NO.1 |
| 71695T | Protector, Rear Seat, NO.2 |
| 71695Y | Protector, Rear Seat, NO.3 |
| 71697M | Protector, Rear Seatback |
| 71701A | Board Sub-assy, Rear Seatback, RH |
| 71701E | Board Sub-assy, NO.2 Rear Seatback, RH |
| 71702D | Board Sub-assy, Rear Seatback, LH |
| 71702E | Board Sub-assy, NO.2 Rear Seatback, LH |
| 71769B | Clip, Seatback Board |
| 71833L | Cover, Rear Seat Reclining, RH |
| 71833N | Cover, Rear NO.2 Seat Reclining, NO.1 RH(FOR LH SEAT) |
| 71833R | Cover, Rear Seat Reclining, RH |
| 71833S | Cover, Rear Seat Reclining, NO.1 RH |
| 71834N | Cover, Rear NO.2 Seat Reclining, NO.1 LH(FOR LH SEAT) |
| 71834R | Cover, Rear Seat Reclining, LH |
| 71834S | Cover, Rear Seat Reclining, NO.1 LH |
| 71843 | Cover, Rear Seat Reclining, NO.2 RH |
| 71843Q | Cover, Rear NO.2 Seat Reclining, NO.2 RH(FOR LH SEAT) |
| 71844H | Cover, Rear Seat Reclining, NO.2 LH |
| 71844M | Cover, Rear Seat Reclining, NO.2 LH |
| 71844P | Cover, Rear NO.2 Seat Reclining, NO.2 LH(FOR LH SEAT) |
| 71845F | Cap, Rear Seat Cover |
| 71848V | Cap, NO.3 Seat Adjuster Cover, RH |
| 71875X | Cover, Reclining Adjuster Inside, RH |
| 71930Q | Support Assy, Rear Seat Headrest |
| 71940M | Headrest Assy, Rear Seat |
| 71960G | Headrest Assy, Rear NO.1 Seat, Center |
| 71970C | Headrest Assy, Rear Seat |
| 71987H | Cable, Rear Seat Headrest |
| 71990B | Support Assy, Rear NO.2 Seat Headrest, RH |
| 71990C | Support Assy, Rear NO.2 Seat Headrest, LH |
| 71H11 | Cover, Reclining Adjuster, RH |
| 71H11A | Cover, Reclining Adjuster, RH |
| 71H11B | Cover, Reclining Adjuster, RH |
| 71H11C | Cover, Reclining Adjuster, RH |
| 71H12 | Cover, Reclining Adjuster, LH |
| 71H12A | Cover, Reclining Adjuster, LH |
| 71H12B | Cover, Reclining Adjuster, LH |
| 71H12C | Cover, Reclining Adjuster, LH |
| 71H75R | Cover, Reclining Adjuster Inside, RH NO.1(FOR LH SEAT) |
| 71H76F | Cover, Reclining Adjuster Inside, LH(FOR REAR NO.1 LH SEAT) |
| 71T76B | Cover, Reclining Adjuster Inside, LH |
| 72057E | Lever Sub-assy, Rear Seat Lock Control, RH NO.1 |
| 72057F | Lever Sub-assy, Rear Seat Lock Control, RH NO.2 |
| 72057J | Lever Sub-assy, Rear Seat Lock Control(FOR RH SEAT) |
| 72057K | Lever Sub-assy, Rear Seat Lock Control(FOR LH SEAT) |
| 72065C | Belt Sub-assy, Rear Seat Hook |
| 72143D | Bracket, Rear Seat Track, Lower Rear RH |
| 72307D | Link Sub-assy, Reclining Control, RH NO.1 |
| 72308C | Link Sub-assy, Reclining Control, LH NO.1 |
| 72329F | Cover, Rear Seat Adjuster Bolt |
| 72329G | Cover, Rear Seat Adjuster Bolt, NO.2 |
| 72525R | Handle, Reclining Adjuster Release, RH |
| 72526L | Handle, Reclining Adjuster Release, LH |
| 72551F | Cover, Reclining Link, RH NO.1 |
| 72551G | Cover, Reclining Link, RH NO.2 |
| 72551N | Cover, Reclining Hinge, RH NO.2(FOR RH SEAT) |
| 72552F | Cover, Reclining Link, LH NO.1 |
| 72552G | Cover, Reclining Link, LH NO.2 |
| 72552Q | Cover, Reclining Hinge, LH NO.2(FOR LH SEAT) |
| 72558C | Stopper, Reclining, NO.1 |
| 72570E | Cable Assy, NO.1 Seat Reclining Adjusting, RH |
| 72580E | Cable Assy, Reclining Adjusting, LH |
| 72607G | Striker Sub-assy, Rear Seat Cushion Lock, NO.1 |
| 72607H | Striker Sub-assy, Rear Seat Cushion Lock, NO.2 |
| 72607J | Striker Sub-assy, Rear Seat Cushion Lock, NO.3 |
| 72615P | Cover, Rear Seatback Lock Striker |
| 72622D | Bush(FOR REAR NO.2 SEAT LEG) |
| 72635D | Hook, Seatback Lock |
| 72650J | Lock Assy, Rear Seat, RH |
| 72660N | Cable Assy, Rear NO.2 Seat Cushion Lock, LH |
| 72660P | Lock Assy, Rear Seat, LH |
| 72690K | Strap Assy, Rear Seat Lock Release |
| 72695Q | Cable, Rear Seat Lock Control |
| 72806E | Holder Sub-assy, Rear Seat Center Armrest Cup |
| 72810L | Armrest Assy, NO.1 Seat, NO.1 |
| 72820B | Armrest Assy, Seat, LH |
| 72830X | Armrest Assy, Rear Seat, Center |
| 72848J | Cap, Seat Armrest, NO.1 |
| 72868A | Cover, Center Armrest Hinge |
| 72921C | Strap, 3RD Seat |
| 72927F | Cover, Rear Seat Cushion Under, RH |
| 72927M | Cover, Rear Seat Cushion Under |
| 72928E | Cover, Rear Seat Cushion Under, LH |
| 72985 | Cover, Rear Headrest, RH |
| 72985A | Cover, Rear Headrest, LH |
| 72995F | Cover, Rear Seat Cushion, RH |
| 72995J | Cover, Rear NO.1 Seat Cushion |
| 72995L | Cover, Rear NO.3 Seat Cushion |
| 72996H | Cover, Rear Seatback |
| 72996J | Cover, Rear Seatback, NO.2 |
| 72998D | Cover, Rear Seat Cushion, LH |
| 74865H | Cover, Center Protector |
| 76971G | Cover, Rear Under |
| 78091D | Cable Sub-assy, Fold Seat Lock Control |
| 78910C | Cable Assy, Fold Seat Lock Control, NO.1(FOR RH SEAT) |
| 78910E | Cable Assy, Fold Seat Lock Control, NO.1 |
| 78920C | Cable Assy, Fold Seat Lock Control, NO.2 |
| 79025B | Pad Sub-assy, NO.2 Seat Cushion |
| 79030C | Leg Assy, Rear NO.2 Seat, RH |
| 79031D | Cover, Sub-assy, NO.3 Seat Cushion |
| 79033B | Cover Sub-assy, NO.3 Seatback, RH |
| 79034A | Cover Sub-assy, NO.3 Seatback, LH |
| 79040C | Leg Assy, Rear NO.2 Seat, LH |
| 79103B | Frame Sub-assy, NO.1 Seatback, RH |
| 79104A | Frame Sub-assy, NO.1 Seatback, LH |
| 79175F | Pad, NO.1 Seatback, RH |
| 79207C | Board Sub-assy, NO.2 Seatback, LH |
| 79207D | Board Sub-assy, NO.2 Seatback, RH |
| 79225D | Carpet, Rear NO.2 Seat Cushion |
| 79236R | Cover, NO.3 Seat Leg |
| 79301D | Frame Sub-assy, NO.3 Seat Cushion |
| 79303B | Frame Sub-assy, NO.3 Seatback, RH |
| 79304B | Frame Sub-assy, NO.3 Seatback, LH |
| 79335B | Pad, NO.3 Seat Cushion, RH |
| 79337B | Carpet, NO.3 Seat Cushion Under |
| 79345B | Pad, NO.3 Seat Cushion, LH |
| 79375C | Pad, NO.3 Seatback, RH |
| 79385 | Pad, NO.3 Seatback, LH |
| 79951B | Cover, NO.1 Seat Cushion, NO.1 |
| 79951C | Cover, NO.1 Seat Cushion, NO.3 |
| 79952A | Cover, NO.1 Seat Cushion, NO.2 |
| 79956V | Cover, Rear Seat Leg Side, RH |
| 79956W | Cover, Rear Seat Leg Side, LH |
| 79959G | Cover, NO.2 Seat Leg, RH NO.1 |
| 79959J | Cover, NO.2 Seat Leg, LH NO.1 |
| 79967T | Cover, Rear NO.1 Seat Leg Side, NO.1 |
| 79967U | Cover, Rear NO.1 Seat Leg Side, NO.2 |
| 79967V | Cover, Rear NO.1 Seat Leg Side, NO.3 |
| 85862G | Blower, Rear Seat Cushion Climate Control |
| 85867D | Blower, NO.1 Seatback Climate Control(FOR RH SEAT) |
| 85867E | Blower, NO.1 Seatback Climate Control(FOR LH SEAT) |
| 87510Y | Heater Assy, Rear NO.1 Seat Cushion, LH |
| 87510Z | Heater Assy, Rear NO.1 Seat Cushion, RH |
| 87530 | Heater Assy, Rear NO.1 Seatback, LH |
| 87530A | Heater Assy, Rear NO.1 Seatback, RH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
