Toyota Land Cruiser Prado

2024-01 → present · chassis GDJ25#,TJA250,TRJ250 · catalogue 781290 · Europe

Supported model Data version 2024-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate

15 part groups · 2 illustrations

Illustrations

Figure 74686BB 74686BB 2024-01 → — Figure 74686CA 74686CA 2024-01 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
11298B Label, Emission Control Information
16793E Label, Cooling Fan Caution
17792D Label, Emission Control Device Information
288A2 Label, Battery Location
42661 Label, Tire Pressure Information
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515A Plate, Theft Warning
74528B Label, Back Door Caution
74543C Label, Rear Seat Information
74559B Label, Fuel Information
74561A Label, Fuel Consumption Information
74567A Plate, E.C.E Approved Number
74584A Label, Towing Caution
88723H Label, Cooler Service Caution
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
