Toyota Land Cruiser
1990-01 → 2001-08 · chassis BJ73,LJ7#,RJ7#,HZJ7#,PZJ7#,KZJ7# · catalogue 781530 · Europe
Discontinued model
Data version 2002-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 15600A — Union(FOR OIL FILTER) | ||||
| 15116-54020 |
Union(FOR OIL FILTER)
1990-01 → 1991-06
ended
|
2LT LJ7# | — | |
| 15116-54021 |
Union(FOR OIL FILTER)
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
| 15116-54021 |
Union(FOR OIL FILTER)
1991-06 → 1993-05
ended
|
2LT LJ7# | — | |
| 90404-20173 |
Union(FOR OIL FILTER)
1990-01 → 1993-05
ended
|
22R RJ70 | — | |
| 90404-27001 |
Union(FOR OIL FILTER)
1990-01 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 90404-27001 |
Union(FOR OIL FILTER)
1990-01 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 15116-54021 |
Union(FOR OIL FILTER)
1993-05 → 1995-01
ended
|
2LT LJ7# | — | |
| 15116-54021 |
Union(FOR OIL FILTER)
1993-05 → 1996-04
ended
|
1KZT KZJ7# | — | |
| 15116-54021 |
Union(FOR OIL FILTER)
1993-05 → 1999-08
ended
|
1HZ HZJ7# | — | |
| 15116-54021 |
Union(FOR OIL FILTER)
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
| 15601 — Filter Sub-assy, Oil | ||||
| 90915-03002 |
Filter Sub-assy, Oil
1990-01 → 1992-04
ended
|
22R# RJ7# | — | |
| 90915-03006 |
Filter Sub-assy, Oil
1990-01 → 1991-06
ended
|
2LT LJ7# | — | |
| 90915-03006 |
Filter Sub-assy, Oil
1990-01 → 1991-06
ended
|
1PZ PZJ7# | — | |
| 90915-03006 |
Filter Sub-assy, Oil
1990-01 → 1991-06
ended
|
1HZ HZJ7# | — | |
| 90915-20001 |
Filter Sub-assy, Oil
1992-04 → 1993-05
ended
|
22R# RJ7# | — | |
| 90915-30002 |
Filter Sub-assy, Oil
1991-06 → 1993-05
ended
|
2LT LJ7# | — | |
| 90915-30002 |
Filter Sub-assy, Oil
1991-06 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 90915-30002 |
Filter Sub-assy, Oil
1991-06 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 90915-20001 |
Filter Sub-assy, Oil
1993-05 → 1996-04
ended
|
22RE RJ7# | — | |
| 90915-30002 |
Filter Sub-assy, Oil
1993-05 → 1995-01
ended
|
2LT LJ7# | — | |
| 90915-30002 |
Filter Sub-assy, Oil
1993-05 → 1996-04
ended
|
1KZT KZJ7# | — | |
| 90915-30002 |
Filter Sub-assy, Oil
1993-05 → 1999-08
ended
|
1HZ HZJ7# | — | |
| 90915-30002 |
Filter Sub-assy, Oil
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
| 15605A — Valve Sub-assy, Oil Check | ||||
| 15605-17020 |
Valve Sub-assy, Oil Check
1990-01 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 15605-17020 |
Valve Sub-assy, Oil Check
1990-01 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 15605-17020 |
Valve Sub-assy, Oil Check
1993-05 → 1999-08
ended
|
1HZ HZJ7# | — | |
| 15605-17020 |
Valve Sub-assy, Oil Check
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
| 15609D — Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET) | ||||
| 90341-18006 note |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1990-01 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 90341-18006 note |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1990-01 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 90341-20002 note |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1990-01 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 90341-20002 note |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1990-01 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 90341-18006 note |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1993-05 → 1998-01
ended
|
1HZ HZJ7# | — | |
| 90341-20002 |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1993-05 → 1996-04
ended
|
1KZT KZJ7# | — | |
| 90341-20002 note |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1993-05 → 1998-01
ended
|
1HZ HZJ7# | — | |
| 90341-20002 |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1998-01 → 1999-08
ended
|
1HZ HZJ7# | — | |
| 90341-20002 |
Plug, W/Head Straight Screw(FOR OIL FILTER BRACKET)
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
| 15691 — Gasket, Oil Filter | ||||
| 15692-54030 |
Gasket, Oil Filter
1990-01 → 1993-05
ended
|
2LT LJ7# | — | |
| 15725-17010 |
Gasket, Oil Filter
1990-01 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 15725-17010 |
Gasket, Oil Filter
1990-01 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 15692-54030 |
Gasket, Oil Filter
1993-05 → 1995-01
ended
|
2LT LJ7# | — | |
| 15725-17010 |
Gasket, Oil Filter
1993-05 → 1999-08
ended
|
1HZ HZJ7# | — | |
| 15725-17010 |
Gasket, Oil Filter
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
| 15721 — Cover, Oil Cooler | ||||
| 15721-17010 |
Cover, Oil Cooler
1990-01 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 15721-17010 |
Cover, Oil Cooler
1990-01 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 15721-17020 note |
Cover, Oil Cooler
1990-01 → 1992-08
ended
|
1PZ PZJ7# | — | |
| 15721-17020 note |
Cover, Oil Cooler
1990-01 → 1993-05
ended
|
1HZ HZJ7# | — | |
| 15721-17022 |
Cover, Oil Cooler
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
| 15721-17010 |
Cover, Oil Cooler
1993-05 → 1994-01
ended
|
1HZ HZJ7# | — | |
| 15721-17020 note |
Cover, Oil Cooler
1993-05 → 1994-01
ended
|
1HZ HZJ7# | — | |
| 15721-17020 |
Cover, Oil Cooler
1994-01 → 1997-05
ended
|
1HZ HZJ7# | — | |
| 15721-17021 |
Cover, Oil Cooler
1997-05 → 1998-01
ended
|
1HZ HZJ7# | — | |
| 15721-17022 |
Cover, Oil Cooler
1998-01 → 1999-08
ended
|
1HZ HZJ7# | — | |
| 15721-17022 |
Cover, Oil Cooler
1999-08 → 2001-08
ended
|
1HZ HZJ7# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
