Toyota Land Cruiser
1990-01 → 2001-08 · chassis BJ73,LJ7#,RJ7#,HZJ7#,PZJ7#,KZJ7# · catalogue 781530 · Europe
Discontinued model
Data version 2002-01
Meter
34 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 83100B | Bulb, Combination Meter, NO.1 |
| 83101 | Socket Sub-assy, Combination Meter Bulb |
| 83110 | Speedometer Assy |
| 83128 | Knob, Trip Counter |
| 83128A | Knob, Meter |
| 83132 | Case, Combination Meter |
| 83133 | Plate, Combination Meter, NO.1 |
| 83134 | Cover, Combination Meter, NO.1 |
| 83138 | Glass, Speedometer |
| 83145 | Lens, Meter, NO.1 |
| 83145A | Lens, Meter, NO.2 |
| 83145B | Lens, Meter, NO.3 |
| 83145C | Lens, Meter, NO.4 |
| 83145P | Dropper, Meter |
| 83147 | Lamp, Meter NO.1 |
| 83147A | Lamp, Meter NO.2 |
| 83147B | Lamp, Meter NO.3 |
| 83147H | Lamp, Meter NO.4 |
| 83180 | Detector Assy, Revolution |
| 83181A | Sensor, Speedometer |
| 83242 | Tachometer Assy, Engine |
| 83243A | Gauge Sub-assy, Fuel Receiver |
| 83244 | Gauge Sub-assy, Water Temperature Receiver |
| 83246 | Gauge, Oil Pressure Receiver |
| 83247 | Plate, Meter Circuit |
| 83247D | Difflock Assy |
| 83290D | Meter Assy, Accessory |
| 83290E | Bulb, Accessory Meter |
| 83293 | Computer, Total Counter Module |
| 83710 | Cable Assy, Speedometer Drive, NO.1 |
| 83783 | Key, Speedmeter Sensor |
| 83847 | Cushion, Combination Speedometer, NO.1 |
| 83910 | Clock Assy |
| 86995 | Plate, Caution (FOR CLINOMETER) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
