Toyota Land Cruiser Prado

2009-08 → 2017-08 · chassis GDJ15#,GRJ150,KDJ15# · catalogue 781560 · Europe

Supported model Data version 2018-02
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Battery & Battery Cable

9 part groups · 2 illustrations

Illustrations

Figure 826696D 826696D 2009-08 → — Figure 826688D 826688D 2009-08 → —

Part groups

PNCDescription
28800 Battery
28800A Terminal, Battery Positive
28800D Cover, Connector(FOR BATTERY TERMINAL)
28800J Terminal, Battery Negative
28800M Terminal, Battery Positive
28800N Terminal, Battery Negative
28800Q Cover, Connector(FOR BATTERY)
28897 Plate, Battery Caution
28898C Plate, Battery
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
