Toyota Lexus GX550/550H
2023-12 → present · chassis TJH252,VJA252 · catalogue 782220 · Europe
Supported model
Data version 2024-02
Floor Mat & Silencer Pad
17 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 58435E | Silencer, Front Floor, Center |
| 58441J | Cover, Battery Service Hole |
| 58441N | Clip(FOR BATTERY SERVICE HOLE COVER) |
| 58510D | Carpet Assy, Floor, Front |
| 58521B | Hook, Floor Carpet |
| 58530B | Clip(FOR FRONT FLOOR CARPET) |
| 58556C | Silencer, Rear Floor |
| 58564H | Clip(FOR REAR FLOOR CARPET) |
| 58574A | Plate, Rear Floor Mat Support, Rear |
| 58582E | Carpet, Rear Floor, Rear |
| 58649C | Cover, Mat Set Plate |
| 58694A | Plate, Mat Set, Upper |
| 58698B | Plate, Mat Set, Lower |
| 64749H | Cover, Back Door Striker |
| 76971H | Cover, Rear Under |
| 76973H | Cover, Rear Under Side, RH |
| 76974J | Cover, Rear Under Side, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
