Toyota Land Cruiser
2021-04 → present · chassis FJA300,GRJ300,VJA300 · catalogue 791270 · Europe
Supported model
Data version 2024-11
Center Support & Planetary Sun Gear (ATM)
33 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 35045 | Spring Sub-assy, Brake Piston Return,NO.2 |
| 35608A | Spring Sub-assy, Brake Piston Return |
| 35608B | Ring, Hole Snap (FOR BRAKE PISTON RETURN SPRING) |
| 35608J | Spring Sub-assy, Brake Piston Return |
| 35608K | Ring, Snap (FOR BRAKE PISTON RETURN SPRING) |
| 35620 | Support Assy, Center |
| 35621 | Piston, Brake, NO.1 |
| 35621V | Piston, Brake, NO.1 |
| 35621X | Ring, O (FOR BRAKE PISTON NO.1) |
| 35622G | Piston, Brake, NO.2 |
| 35622H | Ring, O (FOR BRAKE PISTON NO.2) |
| 35629C | Spring, 1ST & Reverse Brake Plate Stopper |
| 35639B | Spring, Brake Plate Stopper |
| 35676B | Flange, Brake, NO.1 |
| 35678B | Flange, Brake, NO.2 |
| 35678C | Ring, Snap (FOR BRAKE NO.2) |
| 35681A | Disc, Brake, NO.1 |
| 35682A | Disc, Brake, NO.2 |
| 35682B | Ring, Hole Snap(FOR DISC BRAKE NO.2) |
| 35691 | Plate, Brake, NO.1 |
| 35692A | Plate, Brake, NO.2 |
| 35698 | Cylinder, Brake, NO.1 |
| 35699 | Cylinder, Brake, NO.2 |
| 35706H | Gear Sub-assy, Planetary Sun |
| 35706J | Bearing, Thrust Needle Roller (FOR PLANETARY SUN GEAR) |
| 35706P | Gear Sub-assy, Front Planetary Sun |
| 35706S | Race, Thrust Bearing (FOR PLANETARY SUN GEAR FRONT) |
| 35709B | Ring, O (FOR CENTER SUPPORT) |
| 35710G | Gear Assy, Planetary Sun |
| 35787B | Race, Thrust Bearing, NO.2 |
| 35788B | Race, Thrust Bearing, NO.3 |
| 35789E | Race, Thrust Bearing (FOR PLANETARY SUN GEAR) |
| 35790C | Bearing, Thrust Needle Roller |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
