Toyota Land Cruiser

2021-04 → present · chassis FJA300,GRJ300,VJA300 · catalogue 791270 · Europe

Supported model Data version 2024-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Winch

28 part groups · 2 illustrations

Illustrations

Figure 380161A 380161A 2021-04 → — Figure 380162A 380162A 2021-04 → —

Part groups

PNCDescription
28199B Protector, Dust Winch Motor
38110 Winch Assy
38221 Lever, Clutch Hub Shift
38360 Bracket Assy, Winch Roller
38380 Holder Assy, Winch Hook
38600A Motor Assy, W/Magnet Switch, Winch
38601A Yoke Sub-assy, Winch Motor
38603A Armature Sub-assy, Winch Motor
38603B Bearing, NO.1 (FOR WINCH MOTOR ARMATURE)
38603C Bearing, NO.2 (FOR WINCH MOTOR ARMATURE)
38604A Holder Assy, Winch Motor Brush
38610A Motor Assy, Winch
38611B Switch, Magnet, NO.2 (FOR WINCH MOTOR)
38612A Frame, Winch Motor End
38613A Brush, Winch Motor
38613B Spring, Winch Motor Brush
38614A Ring, O(FOR WINCH MOTOR)
38618 Frame, Winch Motor Commutator End
38621B Cover, Magnet Switch Winch
38623 Stopper, Winch Motor
38625 Bolt, Stud Winch Motor
38627 Bushing, Stepped Male Winch Motor
38629 Wire, Winch Motor
38630 Switch Assy, Magnet, NO.1
38639 Wire (FOR WINCH MOTOR)
38640 Switch Assy, Winch Control
38659 Cover, Winch Control Switch
38669 Bracket, Winch Controller
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
