Toyota Land Cruiser
2021-04 → present · chassis FJA300,GRJ300,VJA300 · catalogue 791270 · Europe
Supported model
Data version 2024-11
Rear Seat & Seat Track
186 part groups · 18 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 66310P | Hook Assy, Rope |
| 66990V | Holder Assy, Cup |
| 71015C | Frame Sub-assy, NO.1 Seat Cushion, RH |
| 71016B | Frame Sub-assy, NO.1 Seat Cushion, LH |
| 71075F | Cover Sub-assy, NO.1 Seat Cushion, RH |
| 71076F | Cover Sub-assy, NO.1 Seat Cushion, LH |
| 71251 | Frame, Rear Seatback, RH |
| 71252 | Frame, Rear Seatback, LH |
| 71293B | Plate, Rear Seatback, Upper |
| 71301G | Hinge Sub-assy, Rear NO.1 Seat, RH(FOR RH SEAT) |
| 71301H | Hinge Sub-assy, Rear NO.1 Seat, RH(FOR LH SEAT) |
| 71302C | Hinge Sub-assy, Rear NO.1 Seat, LH(FOR RH SEAT) |
| 71302G | Hinge Sub-assy, Rear NO.1 Seat, LH(FOR LH SEAT) |
| 71430E | Clip |
| 71439C | Clip |
| 71461H | Spring, Rear Seat Cushion |
| 71485E | Cover, Rear Seat Hinge |
| 71486F | Cover, Rear Seat Hinge, LH |
| 71611H | Pad, Rear NO.1 Seat Cushion, RH |
| 71612G | Pad, Rear NO.1 Seat Cushion, LH |
| 71616A | Pad, Rear Seat Cushion |
| 71691N | Cover, Rear Seat Cushion Hinge, Upper RH NO.1 |
| 71691P | Cover, Rear Seat Cushion Hinge, Upper RH NO.2 |
| 71691W | Cover, Rear Seat Cushion Hinge, NO.1 |
| 71691X | Cover, Rear Seat Cushion Hinge, NO.2 |
| 71692L | Cover, Rear Seat Cushion Hinge, Upper LH NO.1 |
| 71692M | Cover, Rear Seat Cushion Hinge, Upper LH NO.2 |
| 71692N | Cover, Rear Seat Cushion Hinge, NO.3 |
| 71692P | Cover, Rear Seat Cushion Hinge, NO.4 |
| 71693P | Cover, Rear Seat Cushion Hinge, Lower RH NO.1 |
| 71693Q | Cover, Rear Seat Cushion Hinge, Lower RH NO.2 |
| 71694G | Cover, Rear Seat Cushion Hinge, Inner LH |
| 71694H | Cover, Rear Seat Cushion Hinge, Lower LH NO.1 |
| 71694J | Cover, Rear Seat Cushion Hinge, Lower LH NO.2 |
| 71695S | Protector, Rear Seat, NO.1 |
| 71695T | Protector, Rear Seat, NO.2 |
| 71695Y | Protector, Rear Seat, NO.3 |
| 71697M | Protector, Rear Seatback |
| 71701A | Board Sub-assy, Rear Seatback, RH |
| 71702D | Board Sub-assy, Rear Seatback, LH |
| 71751D | Hanger, Rear Seat Cover |
| 71769B | Clip, Seatback Board |
| 71779D | Plate, Rear Seat(FOR RH SEAT) |
| 71779E | Plate, Rear Seat(FOR LH SEAT) |
| 71833M | Cover, Rear NO.2 Seat Reclining, NO.1 RH(FOR RH SEAT) |
| 71833N | Cover, Rear NO.2 Seat Reclining, NO.1 RH(FOR LH SEAT) |
| 71833S | Cover, Rear Seat Reclining, NO.1 RH |
| 71833V | Cover, NO.1 Seat Reclining, NO.2 RH |
| 71834M | Cover, Rear NO.2 Seat Reclining, NO.1 LH(FOR RH SEAT) |
| 71834N | Cover, Rear NO.2 Seat Reclining, NO.1 LH(FOR LH SEAT) |
| 71834S | Cover, Rear Seat Reclining, NO.1 LH |
| 71834X | Cover, Rear Seat Reclining, NO.2 LH |
| 71843P | Cover, Rear NO.2 Seat Reclining, NO.2 RH(FOR RH SEAT) |
| 71843Q | Cover, Rear NO.2 Seat Reclining, NO.2 RH(FOR LH SEAT) |
| 71844N | Cover, Rear NO.2 Seat Reclining, NO.2 LH(FOR RH SEAT) |
| 71844P | Cover, Rear NO.2 Seat Reclining, NO.2 LH(FOR LH SEAT) |
| 71848U | Cap, NO.2 Seat Adjuster Cover, RH |
| 71849M | Cap, NO.2 Seat Adjuster Cover, LH |
| 71879H | Cover, Rear Seat Reclining, Inner LH |
| 71881E | Board, Rear NO.1 Seatback, Center |
| 71930H | Support Assy, NO.1 Seat Headrest, RH |
| 71930J | Support Assy, NO.1 Seat Headrest, LH |
| 71930Q | Support Assy, Rear Seat Headrest |
| 71935C | Clip |
| 71936C | Clip |
| 71940F | Headrest Assy, NO.1 Seat, RH |
| 71940G | Headrest Assy, NO.1 Seat, LH |
| 71940H | Headrest Assy, NO.2 Seat, RH |
| 71940J | Headrest Assy, NO.2 Seat, LH |
| 71960G | Headrest Assy, Rear NO.1 Seat, Center |
| 71987H | Cable, Rear Seat Headrest |
| 71F95 | Protector, Rear Seat, NO.4 |
| 71H75L | Cover, Reclining Adjuster Inside, RH NO.1(FOR RH SEAT) |
| 71H75R | Cover, Reclining Adjuster Inside, RH NO.1(FOR LH SEAT) |
| 71H76L | Cover, Reclining Adjuster Inside, LH NO.1(FOR RH SEAT) |
| 71H76N | Cover, Reclining Adjuster Inside, LH NO.1(FOR LH SEAT) |
| 72057J | Lever Sub-assy, Rear Seat Lock Control(FOR RH SEAT) |
| 72057K | Lever Sub-assy, Rear Seat Lock Control(FOR LH SEAT) |
| 72143D | Bracket, Rear Seat Track, Lower Rear RH |
| 72144 | Bracket, Rear Seat Track, Lower Rear LH |
| 72307D | Link Sub-assy, Reclining Control, RH NO.1 |
| 72308C | Link Sub-assy, Reclining Control, LH NO.1 |
| 72329F | Cover, Rear Seat Adjuster Bolt |
| 72329G | Cover, Rear Seat Adjuster Bolt, NO.2 |
| 72525R | Handle, Reclining Adjuster Release, RH |
| 72526L | Handle, Reclining Adjuster Release, LH |
| 72551M | Cover, Reclining Hinge, RH NO.1(FOR RH SEAT) |
| 72551R | Cover, Reclining Hinge, RH NO.1(FOR LH SEAT) |
| 72552K | Cover, Reclining Hinge, LH NO.1(FOR RH SEAT) |
| 72552P | Cover, Reclining Hinge, LH NO.1(FOR LH SEAT) |
| 72558C | Stopper, Reclining, NO.1 |
| 72569B | Plate, Seatback Stopper |
| 72570E | Cable Assy, NO.1 Seat Reclining Adjusting, RH |
| 72574B | Lever, Reclining Control, RH |
| 72580E | Cable Assy, Reclining Adjusting, LH |
| 72607G | Striker Sub-assy, Rear Seat Cushion Lock, NO.1 |
| 72607H | Striker Sub-assy, Rear Seat Cushion Lock, NO.2 |
| 72607J | Striker Sub-assy, Rear Seat Cushion Lock, NO.3 |
| 72607K | Striker Sub-assy, Rear Seat Cushion Lock, NO.4 |
| 72615P | Cover, Rear Seatback Lock Striker |
| 72622D | Bush(FOR REAR NO.2 SEAT LEG) |
| 72630H | Lock Assy, NO.1 Seatback |
| 72635D | Hook, Seatback Lock |
| 72650J | Lock Assy, Rear Seat, RH |
| 72660P | Lock Assy, Rear Seat, LH |
| 72690K | Strap Assy, Rear Seat Lock Release |
| 72695R | Cable, Rear NO.2 Seat Lock Control, RH |
| 72695S | Cable, Rear NO.2 Seat Lock Control, LH |
| 72749G | Spacer, Rear Seat Reclining, RH |
| 72810L | Armrest Assy, NO.1 Seat, NO.1 |
| 72810M | Armrest Assy, NO.1 Seat, NO.2 |
| 72830X | Armrest Assy, Rear Seat, Center |
| 72832B | Plate, Rear Seat Armrest |
| 72868C | Cover, Center Armrest Hinge, RH |
| 72869A | Cover, Center Armrest Hinge, LH |
| 72927F | Cover, Rear Seat Cushion Under, RH |
| 72927G | Cover, Rear NO.2 Seat Cushion Under, RH |
| 72928E | Cover, Rear Seat Cushion Under, LH |
| 72928F | Cover, Rear NO.2 Seat Cushion Under, LH |
| 72985 | Cover, Rear Headrest, RH |
| 72985A | Cover, Rear Headrest, LH |
| 72987B | Cover, Rear Seat Center Armrest |
| 72995F | Cover, Rear Seat Cushion, RH |
| 72996H | Cover, Rear Seatback |
| 72996J | Cover, Rear Seatback, NO.2 |
| 72998D | Cover, Rear Seat Cushion, LH |
| 73930A | Airbag Assy, Rear Seat, RH |
| 73940A | Airbag Assy, Rear Seat, LH |
| 74865H | Cover, Center Protector |
| 76892C | Bush, Rear Seat Lock Assy |
| 76971G | Cover, Rear Under |
| 78910C | Cable Assy, Fold Seat Lock Control, NO.1(FOR RH SEAT) |
| 78910D | Cable Assy, Fold Seat Lock Control, NO.1(FOR LH SEAT) |
| 78950F | Band Assy, Fold Seat Stopper, NO.1 |
| 79013D | Cover Sub-assy, NO.1 Seatback, RH |
| 79014B | Cover Sub-assy, NO.1 Seatback, LH |
| 79021D | Cover Sub-assy, NO.2 Seat Cushion, RH |
| 79022B | Cover Sub-assy, NO.2 Seat Cushion, LH |
| 79023D | Cover Sub-assy, NO.2 Seatback, RH |
| 79024D | Cover Sub-assy, NO.2 Seatback, LH |
| 79030C | Leg Assy, Rear NO.2 Seat, RH |
| 79040C | Leg Assy, Rear NO.2 Seat, LH |
| 79103B | Frame Sub-assy, NO.1 Seatback, RH |
| 79103C | Frame Sub-assy, NO.1 Seatback, Center |
| 79104A | Frame Sub-assy, NO.1 Seatback, LH |
| 79117D | Carpet, NO.1 Seat Cushion |
| 79157B | Cover, NO.1 Seatback Board |
| 79175F | Pad, NO.1 Seatback, RH |
| 79185A | Pad, NO.1 Seatback, LH |
| 79197B | Rivet |
| 79201C | Frame Sub-assy, NO.2 Seat Cushion, RH |
| 79202B | Frame Sub-assy, NO.2 Seat Cushion, LH |
| 79203B | Frame Sub-assy, NO.2 Seatback, RH |
| 79204C | Frame Sub-assy, NO.2 Seatback, LH |
| 79207C | Board Sub-assy, NO.2 Seatback, LH |
| 79207D | Board Sub-assy, NO.2 Seatback, RH |
| 79225D | Carpet, Rear NO.2 Seat Cushion |
| 79235F | Pad, NO.2 Seat Cushion, RH |
| 79236G | Cover, NO.2 Seat Leg, RH |
| 79245A | Pad, NO.2 Seat Cushion, LH |
| 79246H | Cover, NO.2 Seat Leg, LH |
| 79275F | Pad, NO.2 Seatback, RH |
| 79285C | Pad, NO.2 Seatback, LH |
| 79337A | Carpet, NO.2 Seat Cushion Under, RH |
| 79347A | Carpet, NO.2 Seat Cushion Under, LH |
| 79873A | Wire, Fold Seatback |
| 79951B | Cover, NO.1 Seat Cushion, NO.1 |
| 79952A | Cover, NO.1 Seat Cushion, NO.2 |
| 79959G | Cover, NO.2 Seat Leg, RH NO.1 |
| 79959J | Cover, NO.2 Seat Leg, LH NO.1 |
| 79967T | Cover, Rear NO.1 Seat Leg Side, NO.1 |
| 79967U | Cover, Rear NO.1 Seat Leg Side, NO.2 |
| 79967V | Cover, Rear NO.1 Seat Leg Side, NO.3 |
| 79967W | Cover, Rear NO.1 Seat Leg Side, NO.4 |
| 79967X | Cover, Rear NO.1 Seat Leg Side, NO.5 |
| 79J68B | Clip |
| 85860E | Blower Assy, NO.1 Seat Cushion Climate Control(FOR RH SEAT) |
| 85860F | Blower Assy, NO.1 Seat Cushion Climate Control(FOR LH SEAT) |
| 85867D | Blower, NO.1 Seatback Climate Control(FOR RH SEAT) |
| 85867E | Blower, NO.1 Seatback Climate Control(FOR LH SEAT) |
| 87501E | Control Sub-assy, Seat Heater, RH |
| 87501F | Control Sub-assy, Seat Heater, LH |
| 87510Y | Heater Assy, Rear NO.1 Seat Cushion, LH |
| 87510Z | Heater Assy, Rear NO.1 Seat Cushion, RH |
| 87530 | Heater Assy, Rear NO.1 Seatback, LH |
| 87530A | Heater Assy, Rear NO.1 Seatback, RH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
