Toyota Land Cruiser 100
1998-01 → 2007-08 · chassis UZJ100 · catalogue 791450 · Europe
Discontinued model
Data version 2008-01
Height Control (AUTO-LEVELER)
51 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 44545C | Holder, Brake Actuator Bolt |
| 47255B | Grommet, Height Control Reservoir |
| 48901F | Pump Sub-assy, Height Control |
| 48905A | Housing Sub-assy, Height Control |
| 48906A | Link Sub-assy, Height Control Sensor, Rear |
| 48907B | Link Sub-assy, Height Control Sensor, Front |
| 48908D | Cap Sub-assy, Height Control Reservoir |
| 48909B | Strainer Sub-assy, Height Control Oil |
| 48910A | Pump & Motor Assy, Height Control |
| 48912 | Bush, Compressor |
| 48913B | Cover, Height Control Pump |
| 48930C | Reservoir Assy, Height Control |
| 48933C | Cover, Height Control Reservoir Cap |
| 48935A | Bracket, Suspension Control Oil Reservoir |
| 48940 | Valve Assy, Height Control, NO.1 |
| 48964 | Cover, Height Control Case |
| 48965 | Clamp, Height Control Tube |
| 48970 | Bracket Assy, Height Control Compressor |
| 48970A | Bush(FOR HEIGHT CONTROL COMPRESSOR) |
| 48970B | Spacer(FOR HEIGHT CONTROL COMPRESSOR BRACKET) |
| 48974 | Bracket, Height Control Valve |
| 48977B | Joint, Height Control Motor |
| 48979 | Packing, Height Control |
| 48980B | Acuumulator Assy, Height Control |
| 48981 | Tube, Height Control, NO.1 |
| 48982 | Tube, Height Control, NO.2 |
| 48984 | Tube, Height Control, NO.4 |
| 48985 | Tube, Height Control, NO.5 |
| 48986 | Tube, Height Control, NO.6 |
| 48994 | Tube, Height Control, Rear NO.1 |
| 48995 | Tube, Height Control, Rear NO.2 |
| 49040A | Accumulator Assy, Front Suspension Control, LH |
| 49050 | Accumulator Assy, Rear Suspension Control, LH |
| 49130F | Accumulator Assy, Suspension Control Pump |
| 49140 | Accumulator Assy, Front Suspension Control, RH |
| 49141A | Accumulator, Front Suspension Control |
| 49141B | Ring O, Suspension Control Accumulator |
| 49150A | Accumulator Assy, Rear Suspension Control, RH |
| 49151 | Accumulator, Rear Suspension Control |
| 49156 | Ring, Suspension Control Back UP |
| 49161C | Hose, Suspension Control Pressure, NO.1 |
| 49162B | Hose, Suspension Control Pressure, NO.2 |
| 49163B | Hose, Suspension Control Pressure, NO.3 |
| 49164B | Hose, Suspension Control Pressure, NO.4 |
| 49177 | Cap, Bleeder Plug Suspension Control |
| 49189 | Plug, Bleeder Suspension Control |
| 88264B | Motor, Skid Control |
| 89282 | Cover, Suspension Control, FR RH |
| 89283 | Cover, Suspension Control, FR LH |
| 89285 | Cover, Suspension Control, RR RH |
| 89286 | Cover, Suspension Control, RR LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
