Toyota Land Cruiser
1987-08 → 1990-01 · chassis FJ62,HJ6# · catalogue 791530 · Europe
Discontinued model
Data version 1990-06
Front Axle Housing & Differential
56 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 04412B | Gasket Kit, Front Differential Carrier |
| 41101A | Carrier Sub-assy, Differential, Front |
| 41101D | Seal, Oil (FOR FRONT DIFFERENTIAL CARRIER) |
| 41110C | Bolt, Stud (FOR FRONT DIFFERENTIAL CARRIER) |
| 41110F | Carrier Assy, Differential, Front |
| 41114B | Bolt, Front Differential Bearing Cap |
| 41201T | Final Gear Kit, Differential, Front |
| 41204D | Flange Sub-assy, Front Drive Pinion Companion, Front |
| 41211A | Bearing, Tapered Roller (FOR FRONT DRIVE PINION FRONT) |
| 41211B | Bearing, Tapered Roller (FOR FRONT DRIVE PINION REAR) |
| 41214C | Slinger, Front Differential Drive Pinion Oil |
| 41222B | Bolt (FOR FRONT DIFFERENTIAL RING GEAR SET) |
| 41231F | Spacer, Front Differential Drive Pinion Bearing |
| 41252A | Deflector, Dust (FOR FRONT DIFFERENTIAL) |
| 41301N | Bearing(FOR FRONT DIFFERENTIAL CASE) |
| 41301Q | Washer(FOR FRONT DIFFERENTIAL TAPERED ROLLER BEARING) |
| 41315A | Nut, Front Differential Bearing Adjusting |
| 41331F | Gear, Front Differential Side |
| 41341F | Pinion, Front Differential |
| 41342F | Shaft, Front Differential Pinion, NO.1 |
| 41343B | Pin, Front Differential Pinion Shaft |
| 41351F | Washer, Front Differential Pinion Thrust |
| 41361C | Lock, Front Differential Bearing Adjusting Nut |
| 41361F | Washer, Front Differential Side Gear Thrust, NO.1 |
| 41375A | Holder, Front Differential Pinion Shaft |
| 41451A | Fork, Front Differential Lock Shift |
| 41453A | Sleeve, Front Differential Lock |
| 41456B | Cover, Front Differential Lock |
| 41460H | Cylinder Assy, Front Differential Lock |
| 41460K | Ball (FOR FRONT DIFFERENTIAL LOCK CYLINDER) |
| 41460L | Ring, 0 (FOR FRONT DIFFERENTIAL LOCK CYLINDER) |
| 41460M | Bolt, (FOR FRONT DIFFERENTIAL LOCK CYLINDER SET) |
| 41463C | Bolt (FOR FRONT DIFFERENTIAL LOCK SHIFT FORK SHAFT SET) |
| 41464D | Lever, Front Differential Lock Cylinder |
| 41464E | Bush(FOR FRONT DIFFERENTIAL LOCK CYLINDER) |
| 41465H | Retainer, Front Differential Lock Spring |
| 41465J | Plug (FOR FRONT DIFFERENTIAL LOCK CYLINDER) |
| 41465K | Gasket (FOR FRONT DIFFERENTIAL LOCK CYLINDER) |
| 41465L | Spring, Compression(FOR FRONT DIFFERENTIAL LOCK RETAINER) |
| 41466B | Boot, Front Differential Lock Cylinder |
| 43110 | Housing Assy, Front Axle |
| 43110A | Plug Sub-assy, Drain |
| 43110B | Gasket, Drain |
| 43110C | Plug (FOR FRONT AXLE HOUSING) |
| 43110D | Gasket (FOR FRONT AXLE HOUSING PLUG) |
| 43209 | Hose Sub-assy, Front Axle Breather |
| 43209A | Union (FOR FRONT AXLE BREATHER HOSE) |
| 43209B | Clamp (FOR FRONT AXLE BREATHER HOSE) |
| 43209C | Clip, Hose (FOR FRONT AXLE BREATHER HOSE) |
| 43411D | Seal, Type T Oil (FOR FRONT DRIVE SHAFT) |
| 43611 | Gasket, Front Axle Differential Carrier |
| 43631 | Case, Front Axle Differential |
| 43631A | Bearing, Front Axle Differential |
| 43637B | Washer, Plate (FOR FRONT AXLE DRIVE PINION) |
| 43637C | Nut, Castle (FOR FRONT AXLE DRIVE PINION) |
| 43640C | Spacer OR Washer, Front Axle Drive Pinion Thrust |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
