Toyota Land Cruiser
1987-08 → 1990-01 · chassis FJ62,HJ6# · catalogue 791530 · Europe
Discontinued model
Data version 1990-06
Front Floor Panel & Front Floor Member
44 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 51079 | Bracket Sub-assy, Side Step |
| 51088 | Bracket Sub-assy, Side Step, NO.2 |
| 51759A | Cover, Side Door Step Plate, Rear LH |
| 51773B | Cover, Side Door Step Plate, Front RH |
| 51774A | Cover, Side Door Step Plate, Front LH |
| 51779A | Cover, Side Door Step Plate, Rear RH |
| 51781 | Panel, Step, RH |
| 51782 | Panel, Step, LH |
| 51799A | Bracket, Side Step, NO.4 |
| 57405A | Member Sub-assy, Center Floor Cross, NO.2 |
| 57417A | Reinforcement, Front Floor Under |
| 57425 | Reinforcement, Front Floor, NO.2 RH |
| 57426 | Reinforcement, Front Floor, NO.2 LH |
| 57427 | Reinforcement, Front Floor TO Brace |
| 57468B | Bracket, Front Seat, Rear |
| 57483 | Retainer, Differential Lock Lever Support |
| 57511 | Reinforcement, Front Floor, Center |
| 58111 | Pan, Front Floor |
| 58119C | Cushion, Front Floor |
| 58169A | Retainer, Rear Heater Mounting |
| 58171 | Reinforcement, Parking Brake Base |
| 58188A | Bracket, Accelerator Pedal Stopper |
| 58191 | Footrest, Front Floor |
| 58203A | Reinforcement Sub-assy, Center Floor Panel, RH |
| 58204A | Reinforcement Sub-assy, Center Floor Panel, LH |
| 58208 | Pan, Center Floor |
| 58247A | Reinforcement, Rear Seat Cushion Hinge, RH |
| 58248 | Reinforcement, Rear Seat Cushion Lock |
| 58248A | Reinforcement, Rear Seat Cushion Hinge, LH |
| 58262 | Cover, Transmission |
| 58263D | Packing, Transmission Cover |
| 58268B | Seal, Transfer Lever Boot |
| 58286 | Boot, Shift & Select Lever, NO.1 |
| 58291B | Boot, Transfer Shift Lever |
| 58563P | Silencer, Front Floor |
| 58754 | Plate, Engine Service Cover Catch |
| 58845 | Retainer, Winch Lever Boot |
| 58846 | Cover, Winch Lever |
| 58847A | Seal, Winch Lever |
| 58854A | Boot, Winch Lever |
| 59192 | Bracket, Noise Shutter, NO.2 |
| 59195A | Insulator, Noise Shutter |
| 59196B | Insulator, Noise Shutter, LH |
| 59289 | Silencer, Transmission Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
