Toyota Land Cruiser
1990-01 → 1998-01 · chassis FJ80,FZJ80,HDJ80,HZJ80 · catalogue 791540 · Europe
Discontinued model
Data version 1998-01
Back Door Panel & Glass
35 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 64780A | Panel Assy, Back Door Trim |
| 64780C | Panel Assy, Back Door Trim, RH |
| 64790C | Panel Assy, Back Door Trim, LH |
| 65061 | Panel Sub-assy, Tail Gate |
| 67005 | Panel Sub-assy, Back Door |
| 67005D | Panel Sub-assy, Back Door, RH |
| 67006A | Panel Sub-assy, Back Door, LH |
| 67388 | Protector, Back Door Edge |
| 67663 | Garnish, Door Frame, Upper RH |
| 67664 | Garnish, Door Frame, Upper LH |
| 67685 | Packing, Back Door Service Hole, NO.1 |
| 67686 | Packing, Back Door Service Hole, NO.2 |
| 67765A | Cover, Back Door Service Hole, NO.1 |
| 67766 | Cover, Back Door Service Hole, NO.2 |
| 67847 | Cover, Back Door Service Hole, RH |
| 67848 | Cover, Back Door Service Hole, LH |
| 67881A | Weatherstrip, Back Door |
| 67882C | Weatherstrip, Back Door, NO.2 |
| 67884A | Weatherstrip, Back Door, Center |
| 67935B | Garnish, Back Door |
| 67937A | Garnish, Back Door Side |
| 67938A | Garnish, Back Door Side, LH |
| 67939B | Garnish, Back Door, Center |
| 68131 | Glass, Back Door |
| 68131C | Glass, Back Door, RH |
| 68131D | Glass, Back Door, LH |
| 68281B | Weatherstrip, Lift Gate |
| 68291 | Weatherstrip, Back Door Glass |
| 68291D | Weatherstrip, Back Door Glass, RH |
| 68291E | Weatherstrip, Back Door Glass, LH |
| 68611 | Base, Back Door Check, RH |
| 68611A | Base, Back Door Check |
| 68617B | Pin, Back Door Check |
| 68650A | Pin(FOR BACK DOOR CHECK) |
| 68660 | Check Assy, Back Door, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
