Toyota Land Cruiser
1990-01 → 1998-01 · chassis FJ80,FZJ80,HDJ80,HZJ80 · catalogue 791540 · Europe
Discontinued model
Data version 1998-01
Back Door Lock & Hinge
54 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 65706A | Stay Sub-assy, Tail Gate, RH |
| 65707A | Stay Sub-assy, Tail Gate, LH |
| 66110D | Hinge Assy, Tail Gate |
| 67206A | Bracket Sub-assy, Back Door Stopper |
| 67207A | Stopper Sub-assy, Back Door, RH |
| 67207B | Stopper Sub-assy, Back Door, Upper |
| 67207C | Stopper Sub-assy, Back Door |
| 67208 | Stopper Sub-assy, Back Door, NO.2 |
| 67209A | Stopper Sub-assy, Back Door, LH |
| 67836D | Cover, Rear Door Lock Child Protection |
| 67836E | Cover, Rear Door Lock Child Protection |
| 68801 | Hinge Sub-assy, Back Door, Upper RH |
| 68802 | Hinge Sub-assy, Back Door, Upper LH |
| 68803A | Hinge Sub-assy, Back Door, Lower RH |
| 68804A | Hinge Sub-assy, Back Door, Lower LH |
| 68810D | Hinge Assy, Back Door, RH |
| 68838 | Pad, Back Door Hinge, NO.1 |
| 68840 | Hinge Assy, Back Door, LH |
| 68851C | Cover, Back Door Hinge, RH |
| 68852A | Cover, Back Door Hinge, LH |
| 68855A | Protector, Back Door Hinge, Upper RH |
| 68856A | Protector, Back Door Hinge, Upper LH |
| 68857C | Protector, Back Door Hinge, Lower RH |
| 68858C | Protector, Back Door Hinge, Lower LH |
| 68861A | Pad, Back Door Hinge |
| 68950C | Stay Assy, Back Door, RH |
| 68960 | Stay Assy, Back Door, LH |
| 69038 | Protector Sub-assy, Back Door Child |
| 69090 | Handle Assy, Back Door, Outside |
| 69110A | Lock Assy, Back Door W/Motor |
| 69206D | Handle Sub-assy, Back Door Inside, LH |
| 69209A | Handle Sub-assy, Back Door, Inside |
| 69212B | Handle, Back Door Inside |
| 69215 | Handle, Back Door Outside |
| 69277A | Bezel, Back Door Inside Handle |
| 69278D | Bezel, Door Inside Handle, LH |
| 69293C | Snap, Back Door Handle |
| 69350 | Lock Assy, Back Door |
| 69350Q | Lock Assy, Back Door, Upper |
| 69380C | Lock Assy, Back Door, Lower |
| 69390A | Lock Assy, Tail Gate, Lower LH |
| 69410C | Plate Assy, Back Door Lock Striker |
| 69430A | Striker Assy, Back Door Lower Lock |
| 69430C | Striker Assy, Back Door Lock |
| 69450C | Striker Assy, Back Door Lock, RH |
| 69460B | Striker Assy, Back Door Lock, LH |
| 69470C | Striker Assy, Back Door Upper Lock |
| 69690 | Control Assy, Back Door Remote |
| 69741A | Knob, Back Door Lock Control |
| 69789 | Silencer, Back Door Lock Control Link |
| 69790 | Control Assy, Back Door Lock |
| 69790A | Link Assy, Back Door Lock Control |
| 69850C | Link Assy, Back Door Inside Locking |
| 69890 | Link Assy, Back Door Control Handle |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
