Toyota Land Cruiser 100
1998-01 → 2007-08 · chassis HDJ100,UZJ100 · catalogue 791550 · Europe
Discontinued model
Data version 2008-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82151 — Wire, Front Door, RH | ||||
| 82151-60290 |
Wire, Front Door, RH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60291 |
Wire, Front Door, RH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60302 |
Wire, Front Door, RH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60330 |
Wire, Front Door, RH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 LHD | — | |
| 82151-60331 |
Wire, Front Door, RH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 LHD | — | |
| 82151-60342 note |
Wire, Front Door, RH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 LHD VX | — | |
| 82151-60390 note |
Wire, Front Door, RH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60391 note |
Wire, Front Door, RH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60400 note |
Wire, Front Door, RH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 LHD | — | |
| 82151-60401 note |
Wire, Front Door, RH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 LHD | — | |
| 82151-60422 note |
Wire, Front Door, RH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60430 |
Wire, Front Door, RH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 LHD | — | |
| 82151-60303 |
Wire, Front Door, RH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60343 note |
Wire, Front Door, RH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 LHD VX | — | |
| 82151-60423 note |
Wire, Front Door, RH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 RHD | — | |
| 82151-60431 |
Wire, Front Door, RH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 LHD | — | |
| 82151-60303 |
Wire, Front Door, RH
2005-05 → —
|
HDJ100,UZJ100 RHD | — | |
| 82151-60343 note |
Wire, Front Door, RH
2005-05 → —
|
HDJ100,UZJ100 LHD | — | |
| 82151-60423 note |
Wire, Front Door, RH
2005-05 → —
|
HDJ100,UZJ100 RHD | — | |
| 82151-60431 |
Wire, Front Door, RH
2005-05 → —
|
HDJ100,UZJ100 LHD | — | |
| 82152 — Wire, Front Door, LH | ||||
| 82152-60250 |
Wire, Front Door, LH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 LHD | — | |
| 82152-60251 |
Wire, Front Door, LH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 LHD | — | |
| 82152-60252 |
Wire, Front Door, LH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 LHD | — | |
| 82152-60280 |
Wire, Front Door, LH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60281 |
Wire, Front Door, LH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60292 |
Wire, Front Door, LH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60322 note |
Wire, Front Door, LH
2000-08 → 2001-08
ended
|
HDJ100,UZJ100 LHD VX | — | |
| 82152-60330 note |
Wire, Front Door, LH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 LHD | — | |
| 82152-60331 note |
Wire, Front Door, LH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 LHD | — | |
| 82152-60332 note |
Wire, Front Door, LH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 LHD VX | — | |
| 82152-60340 note |
Wire, Front Door, LH
1998-01 → 1999-04
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60341 note |
Wire, Front Door, LH
1999-04 → 2000-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60362 note |
Wire, Front Door, LH
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60253 |
Wire, Front Door, LH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 LHD | — | |
| 82152-60293 |
Wire, Front Door, LH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60333 note |
Wire, Front Door, LH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 LHD VX | — | |
| 82152-60363 note |
Wire, Front Door, LH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 RHD | — | |
| 82152-60253 |
Wire, Front Door, LH
2005-05 → 2006-09
ended
|
HDJ100,UZJ100 LHD | — | |
| 82152-60254 |
Wire, Front Door, LH
2006-09 → —
|
HDJ100,UZJ100 LHD | — | |
| 82152-60293 |
Wire, Front Door, LH
2005-05 → —
|
HDJ100,UZJ100 RHD | — | |
| 82152-60333 note |
Wire, Front Door, LH
2005-05 → —
|
HDJ100,UZJ100 LHD | — | |
| 82152-60363 note |
Wire, Front Door, LH
2005-05 → —
|
HDJ100,UZJ100 RHD | — | |
| 82153 — Wire, Rear Door, NO.1 | ||||
| 82153-60130 |
Wire, Rear Door, NO.1
1998-01 → 1998-06
ended
|
HDJ100,UZJ100 | — | |
| 82153-60131 |
Wire, Rear Door, NO.1
1998-06 → 2000-08
ended
|
HDJ100,UZJ100 | — | |
| 82153-60142 |
Wire, Rear Door, NO.1
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 | — | |
| 82153-60143 note |
Wire, Rear Door, NO.1
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 | — | |
| 82153-60200 note |
Wire, Rear Door, NO.1
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 VX | — | |
| 82153-60143 note |
Wire, Rear Door, NO.1
2005-05 → —
|
HDJ100,UZJ100 | — | |
| 82153-60200 note |
Wire, Rear Door, NO.1
2005-05 → —
|
HDJ100,UZJ100 | — | |
| 82154 — Wire, Rear Door, NO.2 | ||||
| 82153-60130 |
Wire, Rear Door, NO.2
1998-01 → 1998-06
ended
|
HDJ100,UZJ100 | — | |
| 82153-60131 |
Wire, Rear Door, NO.2
1998-06 → 2000-08
ended
|
HDJ100,UZJ100 | — | |
| 82153-60142 |
Wire, Rear Door, NO.2
2000-08 → 2002-08
ended
|
HDJ100,UZJ100 | — | |
| 82153-60143 note |
Wire, Rear Door, NO.2
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 | — | |
| 82153-60200 note |
Wire, Rear Door, NO.2
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 VX | — | |
| 82153-60143 note |
Wire, Rear Door, NO.2
2005-05 → —
|
HDJ100,UZJ100 | — | |
| 82153-60200 note |
Wire, Rear Door, NO.2
2005-05 → —
|
HDJ100,UZJ100 | — | |
| 82505 — Wiring Sub-assy, Front Door, RH | ||||
| 82505-60050 |
Wiring Sub-assy, Front Door, RH
1998-01 → 2002-08
ended
|
HDJ100,UZJ100 RHD | — | |
| 82505-60050 |
Wiring Sub-assy, Front Door, RH
2002-08 → 2005-05
ended
|
HDJ100,UZJ100 VX | — | |
| 82505-60050 |
Wiring Sub-assy, Front Door, RH
2005-05 → 2007-08
ended
|
HDJ100,UZJ100 | — | |
| 82506 — Wiring Sub-assy, Front Door, LH | ||||
| 82506-60040 |
Wiring Sub-assy, Front Door, LH
1998-01 → 2002-08
ended
|
HDJ100,UZJ100 LHD VX | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
