Toyota Lexus LX Series
2021-12 → present · chassis FJA310,VJA310,VJH310 · catalogue 792270 · Europe
Supported model
Data version 2024-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82715X — Bracket, Wiring Harness Clamp, NO.2 | ||||
| 8946A-60130 |
Bracket, Wiring Harness Clamp, NO.2
2024-11 → —
|
VJA310,VJH310 | — | |
| 8946A-60130 |
Bracket, Wiring Harness Clamp, NO.2
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 82716F — Bracket, Wiring Harness Clamp, NO.4 | ||||
| 8946A-60160 |
Bracket, Wiring Harness Clamp, NO.4
2024-11 → —
|
VJA310 | — | |
| 8946A-60420 note |
Bracket, Wiring Harness Clamp, NO.4
2024-11 → —
|
VJH310 CHI | — | |
| 8946A-60450 note |
Bracket, Wiring Harness Clamp, NO.4
2024-11 → —
|
VJH310 CHI | — | |
| 8946A-60470 |
Bracket, Wiring Harness Clamp, NO.4
2024-11 → —
|
VJH310 ARL,GCC | — | |
| 8946A-60160 |
Bracket, Wiring Harness Clamp, NO.4
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 83520 — Gage Assy,Oil Pressure Sender | ||||
| 83520-60060 |
Gage Assy,Oil Pressure Sender
2024-11 → —
|
FJA310 | — | |
| 83520-60070 |
Gage Assy,Oil Pressure Sender
2024-11 → —
|
VJA310,VJH310 | — | |
| 83520-60060 |
Gage Assy,Oil Pressure Sender
2021-12 → 2024-11
ended
|
FJA310 | — | |
| 83520-60070 |
Gage Assy,Oil Pressure Sender
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 89425 — Sensor, Exhaust Gas Temperature | ||||
| 89425-60270 |
Sensor, Exhaust Gas Temperature
2024-11 → —
|
FJA310 ARL,EUR | — | |
| 89425-60270 note |
Sensor, Exhaust Gas Temperature
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60270 note |
Sensor, Exhaust Gas Temperature
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60270 note |
Sensor, Exhaust Gas Temperature
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60350 note |
Sensor, Exhaust Gas Temperature
2024-11 → —
|
VJH310 CHI | — | |
| 89425-60370 note |
Sensor, Exhaust Gas Temperature
2024-11 → —
|
VJH310 CHI | — | |
| 89425-60270 note |
Sensor, Exhaust Gas Temperature
2022-10 → 2023-01
ended
|
FJA310 GCC | — | |
| 89425-60270 note |
Sensor, Exhaust Gas Temperature
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425-60270 |
Sensor, Exhaust Gas Temperature
2021-12 → 2024-11
ended
|
FJA310 ARL,EUR | — | |
| 89425A — Sensor, Exhaust Gas Temperature, NO.2 | ||||
| 89425-60280 |
Sensor, Exhaust Gas Temperature, NO.2
2024-11 → —
|
FJA310 ARL,EUR | — | |
| 89425-60280 note |
Sensor, Exhaust Gas Temperature, NO.2
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60280 note |
Sensor, Exhaust Gas Temperature, NO.2
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60280 note |
Sensor, Exhaust Gas Temperature, NO.2
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60360 note |
Sensor, Exhaust Gas Temperature, NO.2
2024-11 → —
|
VJH310 CHI | — | |
| 89425-60380 note |
Sensor, Exhaust Gas Temperature, NO.2
2024-11 → —
|
VJH310 CHI | — | |
| 89425-60280 note |
Sensor, Exhaust Gas Temperature, NO.2
2022-10 → 2023-01
ended
|
FJA310 GCC | — | |
| 89425-60280 |
Sensor, Exhaust Gas Temperature, NO.2
2021-12 → 2024-11
ended
|
FJA310 ARL,EUR | — | |
| 89425-60280 note |
Sensor, Exhaust Gas Temperature, NO.2
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425B — Sensor, Exhaust Gas Temperature, NO.3 | ||||
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60290 |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 ARL,EUR | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2022-10 → 2023-01
ended
|
FJA310 GCC | — | |
| 89425-60290 |
Sensor, Exhaust Gas Temperature, NO.3
2021-12 → 2024-11
ended
|
FJA310 ARL,EUR | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425-60290 note |
Sensor, Exhaust Gas Temperature, NO.3
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89425C — Sensor, Exhaust Gas Temperature, NO.4 | ||||
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2024-11 → —
|
FJA310 GCC | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2024-11 → —
|
FJA310 ARL | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2024-11 → —
|
FJA310 ARL | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2024-11 → —
|
FJA310 EUR | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2024-11 → —
|
FJA310 EUR | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2024-11 → —
|
FJA310 ARL | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2024-11 → —
|
FJA310 EUR | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2022-10 → 2023-01
ended
|
FJA310 GCC | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2021-12 → 2023-10
ended
|
FJA310 ARL | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2022-10 → 2023-10
ended
|
FJA310 EUR | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2023-10 → 2024-11
ended
|
FJA310 EUR | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2023-10 → 2024-11
ended
|
FJA310 ARL | — | |
| 89425-60300 note |
Sensor, Exhaust Gas Temperature, NO.4
2023-10 → 2024-11
ended
|
FJA310 ARL | — | |
| 89429F — Sensor, Temperature | ||||
| 89429-12010 |
Sensor, Temperature
2024-11 → —
|
VJA310,VJH310 | — | |
| 89429-12010 |
Sensor, Temperature
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 89467B — Sensor, Air Fuel Ratio | ||||
| 89467-60180 |
Sensor, Air Fuel Ratio
2024-11 → —
|
VJA310 | — | |
| 89467-60180 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
VJH310 ARL,GCC | — | |
| 89467-60190 |
Sensor, Air Fuel Ratio
2024-11 → —
|
VJH310 CHI | — | |
| 89467-60190 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
VJH310 ARL,GCC | — | |
| 89467-60220 |
Sensor, Air Fuel Ratio
2024-11 → —
|
FJA310 ARL,EUR | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2024-11 → —
|
FJA310 GCC | — | |
| 89467-60180 |
Sensor, Air Fuel Ratio
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89467-60220 |
Sensor, Air Fuel Ratio
2021-12 → 2024-11
ended
|
FJA310 ARL,EUR | — | |
| 89467-60220 note |
Sensor, Air Fuel Ratio
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89467C — Sensor, Air Fuel Ratio, NO.2 | ||||
| 89467-60190 |
Sensor, Air Fuel Ratio, NO.2
2024-11 → —
|
VJA310 | — | |
| 89467-60340 |
Sensor, Air Fuel Ratio, NO.2
2024-11 → —
|
VJH310 ARL,GCC | — | |
| 89467-60360 note |
Sensor, Air Fuel Ratio, NO.2
2024-11 → —
|
VJH310 CHI | — | |
| 89467-60370 note |
Sensor, Air Fuel Ratio, NO.2
2024-11 → —
|
VJH310 CHI | — | |
| 89467-60190 |
Sensor, Air Fuel Ratio, NO.2
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 89467E — Sensor, Air Fuel Ratio, NO.4 | ||||
| 89467-60210 |
Sensor, Air Fuel Ratio, NO.4
2024-11 → —
|
VJA310 | — | |
| 89467-60380 |
Sensor, Air Fuel Ratio, NO.4
2024-11 → —
|
VJH310 CHI | — | |
| 89467-60210 |
Sensor, Air Fuel Ratio, NO.4
2021-12 → 2024-11
ended
|
VJA310 | — | |
| 89481B — Sensor, Differential Pressure | ||||
| 89481-48010 |
Sensor, Differential Pressure
2024-11 → —
|
VJH310 CHI | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 ARL,EUR | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2024-11 → —
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2023-10 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 GCC | — | |
| 89481-71010 |
Sensor, Differential Pressure
2021-12 → 2024-11
ended
|
FJA310 ARL,EUR | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2022-11 → 2023-01
ended
|
FJA310 GCC | — | |
| 89481-71010 note |
Sensor, Differential Pressure
2022-11 → 2023-01
ended
|
FJA310 GCC | — | |
| 89491 — Sensor, Engine Oil Level | ||||
| 89491-50082 |
Sensor, Engine Oil Level
2024-11 → —
|
FJA310,VJA310,VJH310 | — | |
| 89491-50081 |
Sensor, Engine Oil Level
2021-12 → 2022-04
ended
|
FJA310,VJA310 | — | |
| 89491-50082 |
Sensor, Engine Oil Level
2022-05 → 2024-11
ended
|
FJA310,VJA310 | — | |
| 89615 — Sensor, Knock Control | ||||
| 89615-20090 |
Sensor, Knock Control
2024-11 → —
|
VJA310,VJH310 | — | |
| 89615-20090 |
Sensor, Knock Control
2021-12 → 2024-11
ended
|
VJA310 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
