Toyota Lexus LX Series
2021-12 → present · chassis FJA310,VJA310,VJH310 · catalogue 792270 · Europe
Supported model
Data version 2024-11
Speaker
12 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 86150 | Speaker Assy, W/Box, NO.1 |
| 86160 | Speaker Assy, Front NO.1 |
| 86160B | Speaker Assy, Rear |
| 86160J | Speaker Assy, Front NO.3 |
| 86160L | Speaker Assy, Front NO.4 |
| 86160P | Speaker Assy, Front NO.2 |
| 86160Q | Speaker Assy, Roof |
| 86160Y | Speaker Assy, Rear NO.2 |
| 86160Z | Speaker Assy, Rear NO.3 |
| 86219D | Bracket, Speaker, Rear NO.1 |
| 86240A | Equalizer Assy,Stereo Component |
| 86734D | Microphone, Active Noise Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
