Toyota Lexus LX470
2002-08 → 2007-08 · chassis UZJ100 · catalogue 792550 · Europe
Discontinued model
Data version 2008-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82128 — Wire, Column | ||||
| 82128-60113 |
Wire, Column
2002-08 → 2003-08
ended
|
UZJ100 | — | |
| 82128-60114 |
Wire, Column
2003-08 → 2005-05
ended
|
UZJ100 | — | |
| 82128-60114 |
Wire, Column
2005-05 → —
|
UZJ100 | — | |
| 82136 — Wire, Dash | ||||
| 82136-60473 |
Wire, Dash
2002-08 → 2003-08
ended
|
UZJ100 | — | |
| 82136-60474 |
Wire, Dash
2003-08 → 2004-07
ended
|
UZJ100 | — | |
| 82136-60475 |
Wire, Dash
2004-07 → 2005-05
ended
|
UZJ100 | — | |
| 82136-60476 |
Wire, Dash
2005-05 → —
|
UZJ100 | — | |
| 82136-60B30 note |
Wire, Dash
2005-05 → —
|
UZJ100 | — | |
| 82176 — Wire, Rear Console Box | ||||
| 82176-60060 |
Wire, Rear Console Box
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82176-60060 |
Wire, Rear Console Box
2005-05 → —
|
UZJ100 | — | |
| 82210C — Fusible Link | ||||
| 90982-08283 note |
Fusible Link
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 90982-08284 note |
Fusible Link
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 90982-08285 note |
Fusible Link
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 90982-08291 note |
Fusible Link
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 90982-08283 note |
Fusible Link
2005-05 → —
|
UZJ100 | — | |
| 90982-08284 note |
Fusible Link
2005-05 → —
|
UZJ100 | — | |
| 90982-08285 note |
Fusible Link
2005-05 → —
|
UZJ100 | — | |
| 90982-08291 note |
Fusible Link
2005-05 → —
|
UZJ100 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
