Toyota Lexus LX470
2002-08 → 2007-08 · chassis UZJ100 · catalogue 792550 · Europe
Discontinued model
Data version 2008-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82155 — Wire, Center Piller, NO.1 | ||||
| 82155-60021 |
Wire, Center Piller, NO.1
2002-08 → 2003-03
ended
|
UZJ100 | — | |
| 82155-60022 |
Wire, Center Piller, NO.1
2003-03 → 2005-05
ended
|
UZJ100 | — | |
| 82155-60022 |
Wire, Center Piller, NO.1
2005-05 → —
|
UZJ100 | — | |
| 82155-60040 note |
Wire, Center Piller, NO.1
2005-05 → —
|
UZJ100 | — | |
| 82171 — Wire, Roof, NO.1 | ||||
| 82171-60652 |
Wire, Roof, NO.1
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82171-60653 |
Wire, Roof, NO.1
2005-05 → —
|
UZJ100 | — | |
| 82172 — Wire, Roof, NO.2 | ||||
| 82172-60120 |
Wire, Roof, NO.2
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82172-60120 |
Wire, Roof, NO.2
2005-05 → —
|
UZJ100 | — | |
| 82173 — Wire, Roof, NO.3 | ||||
| 82173-60090 |
Wire, Roof, NO.3
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82173-60090 |
Wire, Roof, NO.3
2005-05 → —
|
UZJ100 | — | |
| 82186 — Wire, Rear Window, NO.1 | ||||
| 82186-60040 |
Wire, Rear Window, NO.1
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82186-60040 |
Wire, Rear Window, NO.1
2005-05 → 2007-08
ended
|
UZJ100 | — | |
| 82188B — Wire, Back Door, Upper | ||||
| 82188-60060 |
Wire, Back Door, Upper
2002-08 → 2003-08
ended
|
UZJ100 | — | |
| 82188-60061 |
Wire, Back Door, Upper
2003-08 → 2005-05
ended
|
UZJ100 | — | |
| 82188-60061 |
Wire, Back Door, Upper
2005-05 → —
|
UZJ100 | — | |
| 82188-60080 note |
Wire, Back Door, Upper
2005-05 → —
|
UZJ100 | — | |
| 82189A — Wire, Back Door, Lower | ||||
| 82189-60050 |
Wire, Back Door, Lower
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82189-60051 |
Wire, Back Door, Lower
2005-05 → —
|
UZJ100 | — | |
| 82817A — Protector, Wiring Harness, NO.2 | ||||
| 82817-60440 |
Protector, Wiring Harness, NO.2
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82817-60440 |
Protector, Wiring Harness, NO.2
2005-05 → —
|
UZJ100 | — | |
| 82817B — Protector, Wiring Harness, NO.3 | ||||
| 82817-60450 |
Protector, Wiring Harness, NO.3
2002-08 → 2005-05
ended
|
UZJ100 | — | |
| 82817-60450 |
Protector, Wiring Harness, NO.3
2005-05 → —
|
UZJ100 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
