Toyota Coaster
1977-08 → 1982-04 · chassis RB1#,BB10 · catalogue 811210 · Europe
Discontinued model
Data version 1982-12
Roof Headlining & Silencer Pad
66 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 63152 | Plate, Roof Board Set Corner, Front RH |
| 63152A | Plate, Roof Board Set Corner |
| 63153 | Plate, Roof Board Set Corner, Front LH |
| 63156 | Plate, Roof Board Set Corner, Rear RH |
| 63157 | Plate, Roof Board Set Corner, Rear LH |
| 63166 | Bracket, Grille Holder Base Set, Front |
| 63167 | Bracket, Grille Holder Base Set, Rear |
| 63168 | Bracket, Roof Duct Ornament Set |
| 63201 | Plate Sub-assy, Roof Board Set, Front |
| 63202 | Plate Sub-assy, Roof Board Set Side, Front |
| 63203 | Plate Sub-assy, Roof Board Set Side, Center |
| 63204 | Plate Sub-assy, Roof Board Set Side, Rear RH |
| 63205 | Plate Sub-assy, Roof Board Set Side, Rear LH |
| 63206 | Plate Sub-assy, Roof Board Set, Rear |
| 63257 | Pad, Grille Holder Base Set Bracket Insulation |
| 63258 | Pad, Room Duct Ornament Set Bracket Insulation |
| 63284 | Hook, Cooler Duct, Upper |
| 63319 | Moulding, Roof Inner Board Set, Rear |
| 63319A | Moulding, Roof Vinyl, NO.1 Rear |
| 63321 | Board, Roof, NO.1 |
| 63322 | Board, Roof, NO.2 |
| 63323 | Board, Roof, NO.3 |
| 63324 | Board, Roof, NO.4 |
| 63325 | Board, Roof, NO.5 |
| 63331 | Moulding, Roof Vinyl, Front |
| 63332 | Moulding, Roof Vinyl, Rear |
| 63333 | Moulding, Roof Vinyl, Side, RH |
| 63374 | Moulding, Roof Board Set |
| 63374A | Moulding, Roof Inner Board Set, Side |
| 63374B | Support, Roof Inner Board Set Moulding |
| 63375 | Moulding, Roof Vinyl |
| 63375A | Moulding, Roof Vinyl, NO.2 |
| 63422 | Pad, Roof Duct Insulation, Upper Front |
| 63423 | Pad, Roof Duct Insulation, Upper Center |
| 63424 | Pad, Roof Duct Insulation, Upper Rear |
| 63431 | Pad, Front Duct Insulation, Lower Front |
| 63432 | Pad, Roof Duct Insulation, Lower Center |
| 63433 | Pad, Roof Duct Insulation, Lower Rear |
| 63441 | Duct, Cooler, Front |
| 63443 | Duct, Cooler, Rear |
| 63446 | Duct, Cooler, Side |
| 63498 | Bracket, Roof Headlining, Rear RH |
| 63499 | Bracket, Roof Headlining, Rear LH |
| 63631 | Lining, Roof Header, Front |
| 63632 | Lining, Roof Header, Rear |
| 63634 | Lining, Roof Side Inner, NO.2 RH |
| 63635 | Lining, Roof Side Inner, NO.3 RH |
| 63636 | Lining, Roof Side Inner, NO.4 RH |
| 63642 | Insulator, Cooler Duct, Front |
| 63644 | Lining, Roof Side Inner, NO.2 LH |
| 63645 | Lining, Roof Side Inner, NO.3 LH |
| 63646 | Lining, Roof Side Inner, NO.4 LH |
| 63649 | Insulator, Cooler Duct, Rear |
| 63651 | Insulator, Roof Panel, NO.1 |
| 63652 | Insulator, Roof Panel, NO.2 |
| 63653 | Insulator, Roof Panel, NO.3 |
| 63654 | Insulator, Roof Panel, NO.4 |
| 63655 | Insulator, Roof Panel, NO.5 |
| 63656 | Insulator, Roof Panel, NO.6 |
| 63657 | Insulator, Roof Panel, NO.7 |
| 63658 | Insulator, Roof Panel, NO.8 |
| 63661 | Moulding, Side Inner Roof, NO.1 |
| 63662 | Moulding, Side Inner Roof, NO.2 |
| 63663 | Moulding, Side Inner Roof, NO.3 |
| 63664 | Moulding, Side Inner Roof, NO.4 |
| 63688 | Cushion, Roof Side Reinforcement |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
