Toyota Coaster
1982-05 → 1993-01 · chassis RB2#,BB2#,3#,HB3#,FB30,HDB30,HZB30 · catalogue 811220 · Europe
Discontinued model
Data version 1994-03
Front Door Panel & Glass
58 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 61295 | Bracket, Front Door Check Arm |
| 62275A | Cover, Front Door Window, Upper |
| 62285A | Cover, Front Door Window, Lower |
| 62384F | Cap,Front Door Window |
| 62385A | Seal, Front Door Window, NO.1 |
| 62386A | Seal, Front Door Window, NO.2 |
| 62411G | Run, Front Door Window, Front |
| 62412C | Run, Front Door Window, Front Upper |
| 62413B | Run, Front Door Window, Front Lower |
| 62415B | Run, Front Door Window, Rear |
| 62416B | Run, Front Door Window, Rear Upper |
| 62417A | Run, Front Door Window, Rear Lower |
| 62722 | Weatherstrip, Front Door Window Water Proof |
| 62723 | Weatherstrip, Front Door Window Water Proof, Upper |
| 62724 | Weatherstrip, Water Proof |
| 67001 | Panel Sub-assy, Front Door, RH |
| 67002 | Panel Sub-assy, Front Door, LH |
| 67027 | Cover Sub-assy, Door Ventilating Hole |
| 67120 | Sash Assy, Front Door Outer |
| 67120B | Piece, Front Door Window Water Proof |
| 67120C | Piece, Front Window Water Proof |
| 67120E | Stopper, Front Door Window, Rear |
| 67120F | Clip, Front Door Window Outer Sash |
| 67121 | Sash, Front Door Inner, Front |
| 67121A | Weatherstrip, Front Door Inner, Front NO.1 |
| 67121B | Weatherstrip, Front Door Inner, Front NO.2 |
| 67121C | Guide, Front Door Sash |
| 67121H | Stopper, Front Door Window |
| 67122 | Sash, Front Door Inner, Rear |
| 67122A | Weatherstrip, Front Door Inner, Rear NO.1 |
| 67122B | Weatherstrip, Front Door Inner, Rear NO.2 |
| 67122D | Guide, Front Door Sash |
| 67123 | Sash, Front Door Window Inner, Center |
| 67124 | Lock, Front Door Window, Front |
| 67125 | Lock, Front Door Window, Rear |
| 67601 | Board Sub-assy, Front Door Trim, RH |
| 67602 | Board Sub-assy, Front Door Trim, LH |
| 67611 | Board, Front Door Trim, Upper RH |
| 67612 | Board, Front Door Trim, Upper LH |
| 67777 | Pocket, Front Door Trim, RH |
| 67778 | Pocket, Front Door Trim, LH |
| 67801 | Cover Sub-assy, Front Door Hole, NO.1 RH |
| 67802 | Cover Sub-assy, Front Door Hole, NO.1 LH |
| 67805 | Cover Sub-assy, Front Door Hole, NO.2 RH |
| 67806 | Cover Sub-assy, Front Door Hole, NO.2 LH |
| 67837 | Protector, Front Door Service Hole Cover |
| 67861 | Weatherstrip, Front Door, RH |
| 67861A | Retainer(FOR FRONT DOOR WEATHERSTRIP) |
| 67862 | Weatherstrip, Front Door, LH |
| 67863A | Weatherstrip, Front Door, Upper RH |
| 67864A | Weatherstrip, Front Door, Upper, LH |
| 67865 | Weatherstrip, Front Door, Lower RH |
| 67866 | Weatherstrip, Front Door Lower, LH |
| 67867 | Clip, Door Weatherstrip |
| 68101 | Glass Sub-assy, Front Door, RH |
| 68102 | Glass Sub-assy, Front Door, LH |
| 68610 | Check Assy, Front Door |
| 68610A | Pin(FOR FRONT DOOR CHECK) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
