Toyota Coaster
1993-01 → 2016-12 · chassis BB4#,5#,BZB40,50,HZB50,RZB40,50,TRB40,50,XZB40,5# · catalogue 811230 · Europe
Discontinued model
Data version 2016-12
Mechanical Governor
87 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 22013 | Housing Sub-assy, Fullroad Stopper |
| 22013B | Ring, O(FOR FULLROAD STOPPER HOUSING) |
| 22013C | Housing, Fullroad Stopper, NO.2 |
| 22015 | Lever Sub-assy, Floating |
| 22157A | Plug(FOR NB BOOST COMPENSATOR) |
| 22185 | Plate, Tappet Adjusting Shim(FOR NB BOOST COMPENSATOR) |
| 22329B | Bolt, Diaphragm Connecting, NO.3 |
| 22338B | Pin, Lever Conecting |
| 22408 | Arm, Stopper |
| 22408A | Arm Sub-assy(FOR CONTROL LACK) |
| 22408B | Spring, Return(FOR ARM) |
| 22408C | Nut, Arm |
| 22409 | Lever Sub-assy, Supproting |
| 22410 | Governor Assy, Injection Pump Mechanical |
| 22412 | Spring, Mechanical Governor |
| 22416 | Washer, Governor Lock |
| 22419B | Washer, Plate(FOR STOPPER LEVER) |
| 22419C | Spring, Return(FOR STOPPER LEVER) |
| 22419D | Ring, O(FOR STOPPER LEVER) |
| 22420 | Housing Sub-assy, Mechanical Governor |
| 22421 | Spring, Idling |
| 22421C | Washer, Idling Spring |
| 22424A | Arm, Spring |
| 22424B | Spring, Return(FOR SPRING ARM) |
| 22432B | Shim |
| 22433A | Screw, Adapter(FOR SLIDING BLOCK) |
| 22433B | Spring(FOR ADAPTER SCREW) |
| 22433C | Bush(FOR ADAPTER SCREW) |
| 22433D | Adapter, NB Boost Compensator |
| 22434 | Shackle |
| 22437C | Nut, Cap(FOR NB BOOST COMPENSATOR) |
| 22438B | Screw, Stop(FOR NB BOOST COMPENSATOR) |
| 22440 | Flyweight Sub-assy |
| 22442A | Gasket, Governor |
| 22456 | Screw, Stop |
| 22460 | Lever Sub-assy, Support |
| 22460D | Washer, Lock(FOR STEERING LEVER) |
| 22460E | Arm Assy, Guide |
| 22461 | Plug, Screw |
| 22465A | Key, Woodruff(FOR ADJUSTING LEVER) |
| 22465B | Seal, Oil(FOR ADJUSTING LEVER) |
| 22467 | Nut, Round |
| 22468 | Cover, Plate |
| 22468A | O, Ring |
| 22471A | Shaft, Lever Supporting |
| 22480 | Cover Sub-assy, Governor |
| 22480E | Gasket, Governor Cover |
| 22481A | Seat, Spring, Inner |
| 22540A | Compensator Sub-assy, Boost(FOR NB PUMP) |
| 22540B | Ring, O(FOR NB BOOST COMPENSATOR) |
| 22542B | Diaphragm, NB Boost Compensator |
| 22546A | Spring(FOR NB BOOST COMPENSATOR) |
| 22549A | Washer, Thrust(FOR NB BOOST COMPENSATOR) |
| 22551 | Seat, Spring(FOR FLYWEIGHT) |
| 22552A | Spring, Return(FOR CAM PLATE) |
| 22552C | Washer(FOR CAM PLATE BUSH) |
| 22554 | Bushing(FOR NB BOOST COMPENSATOR) |
| 22557 | Cam, Full Stop |
| 22557A | Pin, Connecting(FOR FULL STOP CAM) |
| 22557B | Washer, Plate(FOR CONNECTING PIN) |
| 22557C | Ring, E(FOR CONNECTING PIN) |
| 22558 | Shaft, Sliding Block |
| 22558A | Spring(FOR SLIDING BLOCK SHAFT) |
| 22579 | Actuator, Fuel Cut |
| 22687 | Rod, Push(FOR BELLOWS) |
| 22702 | Lever Assy, Floating |
| 22702B | Washer, Plate(FOR FLOATING LEVER) |
| 22702C | Arm, Floating |
| 22702E | Lever Sub-assy, Control |
| 22703C | Cover Sub-assy, Governor |
| 22711 | Housing, NB Boost Compensator |
| 22723 | Damper, Flyweight Holder |
| 22725 | Spring, Idling |
| 22726A | Spring, Speed Control |
| 22728A | Guide, Spring |
| 22729 | Nut, Adjusting(FOR FLYWEIGHT) |
| 22730 | Bushing Assy, Camshaft |
| 22738 | Bushing, Guide(FOR FLYWEIGHT) |
| 22745A | Flyweight, Distributive Pump |
| 22749A | Collar, Thrust(FOR NB INJECTION PUMP) |
| 22761 | Slider(FOR SPEED CONTROL) |
| 22761A | Shaft, Sliding Weight |
| 22761B | Block, Sliding |
| 22776B | Nut, Cap(FOR SCREW STOPPER) |
| 22776C | Screw, Stopper |
| 22795 | Plug, Screw |
| 22795B | Gasket, Screw Plug |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
