Toyota Sienta (JPP)
2022-07 → present · chassis MXPC10,MXPL10 · catalogue 119340 · General
Supported model
Data version 2022-07
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 47101A — Spring(FOR BRAKE PEDAL RETURN) | ||||
| 90506-17003 |
Spring(FOR BRAKE PEDAL RETURN)
2022-07 → 2024-05
ended
|
MXPC10 N | — | |
| 90506-17003 |
Spring(FOR BRAKE PEDAL RETURN)
2022-07 → —
|
MXPL10;MXPC10 U | — | |
| 47110 — Support Assy, Brake Pedal | ||||
| 47110-52530 |
Support Assy, Brake Pedal
2022-07 → 2024-05
ended
|
MXPC10 N | — | |
| 47110-52530 |
Support Assy, Brake Pedal
2022-07 → 2025-08
ended
|
MXPC10 U | — | |
| 47110-52540 |
Support Assy, Brake Pedal
2022-07 → 2025-08
ended
|
MXPL10 | — | |
| 47121 — Pad, Brake Pedal | ||||
| 47121-47010 |
Pad, Brake Pedal
2022-07 → 2024-05
ended
|
MXPC10 N | — | |
| 47121-47010 |
Pad, Brake Pedal
2022-07 → 2025-08
ended
|
MXPL10;MXPC10 U | — | |
| 47264A — Pin(FOR PUSH ROD) | ||||
| 90249-08256 |
Pin(FOR PUSH ROD)
2022-07 → 2024-05
ended
|
MXPC10 N | — | |
| 90249-08256 |
Pin(FOR PUSH ROD)
2022-07 → —
|
MXPL10;MXPC10 U | — | |
| 55172A — Base, Brake Pedal Support | ||||
| 55172-52060 |
Base, Brake Pedal Support
2022-07 → 2024-05
ended
|
MXPC10 N | — | |
| 55172-52060 |
Base, Brake Pedal Support
2022-07 → —
|
MXPL10;MXPC10 U | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
