Toyota Vios/Yaris/Yarisativ
2022-08 → present · chassis NGC10#,NYC100 · catalogue 11G210 · General
Supported model
Data version 2023-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 17308B — Hose Sub-assy, Vacuum | ||||
| 77754-BZ430 |
Hose Sub-assy, Vacuum
2022-08 → —
|
1NRVE,2NRVE NGC101,102 RHD GEN | — | |
| 77754-BZ450 |
Hose Sub-assy, Vacuum
2023-03 → —
|
2NRVE NGC102 MA | — | |
| 77754-BZ460 |
Hose Sub-assy, Vacuum
2022-08 → —
|
1NRVE,2NRVE NGC101,102 LHD | — | |
| 77754-BZ480 |
Hose Sub-assy, Vacuum
2022-08 → —
|
3NRVE NGC100 | — | |
| 23827A — Hose, Fuel Vapor Feed, NO.2 | ||||
| 23827-BZ130 |
Hose, Fuel Vapor Feed, NO.2
2022-08 → —
|
1NRVE,2NRVE NGC101,102 | — | |
| 23841G — Clamp, Fuel Hose | ||||
| 9004A-46363 |
Clamp, Fuel Hose
2022-08 → —
|
1NRVE,2NRVE NGC101,102 | — | |
| 25860 — Valve Assy, Vacuum Switching, NO.1 | ||||
| 25860-0Y190 |
Valve Assy, Vacuum Switching, NO.1
2022-08 → —
|
3NRVE NGC100 | — | |
| 25860-BZ050 |
Valve Assy, Vacuum Switching, NO.1
2022-08 → —
|
1NRVE,2NRVE NGC101,102 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
