Toyota Vios/Yaris/Yarisativ
2022-08 → present · chassis NGC10#,NYC100 · catalogue 11G210 · General
Supported model
Data version 2023-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 81250 — Lamp Assy, Room, NO.2 | ||||
| 81250-30210 |
Lamp Assy, Room, NO.2
2022-08 → —
|
NGC10# | — | |
| 81250B — Bulb, Room Lamp, NO.2 | ||||
| 90981-11013 note |
Bulb, Room Lamp, NO.2
2022-08 → —
|
NGC10# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
