Toyota Glanza
2019-04 → present · chassis K12M,K12N · catalogue 132310 · General
Supported model
Data version 2019-11
Mat & Carpet
5 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 55215D | Pad, Dash Panel Insulator, NO.3 |
| 58510D | Carpet Assy, Floor, Front |
| 58520C | Clip(FOR FRONT FLOOR CARPET) |
| 58521B | Hook, Floor Carpet |
| 58694C | Grommet(FOR MAT SET PLATE) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
