Toyota Etios

2012-09 → present · chassis NGK1# · catalogue 137310 · General

Supported model Data version 2018-02
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Rear Seat & Seat Track

17 part groups · 2 illustrations

Illustrations

Figure 71A231C 71A231C 2012-09 → — Figure 71A232C 71A232C 2012-09 → —

Part groups

PNCDescription
71017A Frame Sub-assy, Rear Seatback
71075B Cover, Rear Seat Cushion (FOR BENCH TYPE)
71077B Cover, Rear Seatback (FOR BENCH TYPE)
71315B Pin, Rear Seat Hinge
71611 Pad, Rear Seat Cushion
71651B Pad, Rear Seatback(FOR BENCH TYPE)
71657 Cloth, Rear Seatback Under
71931A Support, Rear Seat Headrest
71940A Headrest Assy, Rear Seat
71956B Support, Rear Seat Headrest
71960B Headrest Assy, Rear Seat, Center
71970 Headrest Assy, Rear Seat
72630C Lock Assy, Rear Seatback, RH
72640A Lock Assy, Rear Seatback, LH
72641 Pin, Rear Seatback Lock
73705B Bracket Sub-assy, Cross Anchor
79977 Felt, Seatback
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
