Toyota Urban Cruiser
2020-12 → present · chassis K15BR-HS###N · catalogue 138310 · General
Supported model
Data version 2020-12
Floor Pan & Lower Back Panel
24 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 57051A | Member Sub-assy, Front Floor Cross, RH |
| 57052A | Member Sub-assy, Front Floor Cross, LH |
| 57453C | Member, Front Floor Cross Side, RH |
| 57454B | Member, Front Floor Cross Side, LH |
| 57661D | Member, Rear Floor Cross, Front |
| 57803B | Reinforce Sub-assy, Belt Anchor, NO.2 RH |
| 57804A | Reinforce Sub-assy, Belt Anchor, NO.2 LH |
| 57805F | Reinforcement Sub-assy, Belt Anchor, NO.1 |
| 57837 | Reinforcement, Rear NO.1 Seat Leg, Rear NO.3 |
| 57838 | Reinforcement, Rear NO.1 Seat Leg, Rear NO.4 |
| 58111A | Pan, Front Floor, RH |
| 58112C | Pan, Front Floor, LH |
| 58113A | Panel, Front Floor, Center |
| 58159B | Sheet, Front Floor |
| 58211H | Pan, Center Floor |
| 58212C | Pan, Center Floor, Front |
| 58251B | Brace, Floor Panel, Front |
| 58307 | Panel Sub-assy, Body Lower Back |
| 58311 | Pan, Rear Floor |
| 58313 | Panel, Rear Floor Side, RH |
| 58314 | Panel, Rear Floor Side, LH |
| 58351E | Bracket, Spare Wheel Clamp |
| 58365A | Bracket, Fuel Tank Support, RH |
| 58621F | Silencer, Center Console, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
