Toyota Urban Cruiser
2022-11 → present · chassis FG21###,22###,61###,62### · catalogue 138320 · General
Supported model
Data version 2024-04
Back Door Lock & Handle
7 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 68820C | Hinge Assy, Back Door, LH |
| 68950C | Stay Assy, Back Door, RH |
| 68960B | Stay Assy, Back Door, LH |
| 68961 | Bolt, Back Door Stay |
| 69350 | Lock Assy, Back Door |
| 69430C | Striker Assy, Back Door Lock |
| 74811G | Handle, Door Pull |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
