Toyota Rumion

2021-08 → present · chassis K15B · catalogue 139310 · General

Supported model Data version 2022-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Back Door Lock & Handle

10 part groups · 2 illustrations

Illustrations

Figure 67B780A 67B780A 2021-08 → — Figure 67B781 67B781 2021-08 → —

Part groups

PNCDescription
68810C Hinge Assy, Back Door, RH
68820C Hinge Assy, Back Door, LH
68947 Bracket, Back Door Damper Stay, Lower RH
68948 Bracket, Back Door Damper Stay, Lower LH
68950C Stay Assy, Back Door, RH
68960B Stay Assy, Back Door, LH
69293 Handle, Back Door
69350 Lock Assy, Back Door
69430C Striker Assy, Back Door Lock
69792 Link, Back Door Lock Locking
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
