Toyota Starlet Cross

2024-04 → present · chassis K15B · catalogue 13E310 · General

Supported model Data version 2024-04
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Back Door Lock & Handle

7 part groups · 2 illustrations

Illustrations

Figure 67D1H4 67D1H4 2024-04 → — Figure 67D1H5 67D1H5 2024-04 → —

Part groups

PNCDescription
68810 Hinge Assy, Back Door, Upper
68950C Stay Assy, Back Door, RH
68960B Stay Assy, Back Door, LH
68961 Bolt, Back Door Stay
69350 Lock Assy, Back Door
69351B Holder, Back Door Switch
69430C Striker Assy, Back Door Lock
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
