Toyota Tercel
1994-09 → 1999-07 · chassis EL50,53 · catalogue 141350 · General
Discontinued model
Data version 2000-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 44201 — Valve Sub-assy, Power Steering Control | ||||
| 44201-16070 |
Valve Sub-assy, Power Steering Control
1996-03 → 1996-07
ended
|
EL53 | — | |
| 44201-16070 |
Valve Sub-assy, Power Steering Control
1994-09 → 1996-03
ended
|
EL5# LHD | — | |
| 44201-16140 |
Valve Sub-assy, Power Steering Control
1994-09 → 1997-12
ended
|
EL50 RHD | — | |
| 44201-16200 |
Valve Sub-assy, Power Steering Control
1996-07 → 1996-10
ended
|
EL53 | — | |
| 44201-16200 |
Valve Sub-assy, Power Steering Control
1996-03 → 1996-07
ended
|
EL50 LHD | — | |
| 44201-16221 |
Valve Sub-assy, Power Steering Control
1996-10 → 1999-07
ended
|
EL5# LHD | — | |
| 44201-16221 |
Valve Sub-assy, Power Steering Control
1996-07 → 1996-10
ended
|
EL50 LHD | — | |
| 44201-16230 |
Valve Sub-assy, Power Steering Control
1997-12 → 1999-07
ended
|
EL50 RHD | — | |
| 44201A — Nut, Lock(FOR POWER STEERING CONTROL VALVE) | ||||
| 94184-61200 |
Nut, Lock(FOR POWER STEERING CONTROL VALVE)
1994-09 → —
|
EL5# LHD | — | |
| 44201C — Ring(FOR POWER STEERING CONTROL VALVE) | ||||
| 90560-33005 |
Ring(FOR POWER STEERING CONTROL VALVE)
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 90562-33007 |
Ring(FOR POWER STEERING CONTROL VALVE)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44201F — Seal, Oil(FOR POWER STEERING CONTROL VALVE) | ||||
| 90311-19010 |
Seal, Oil(FOR POWER STEERING CONTROL VALVE)
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 90311-19011 |
Seal, Oil(FOR POWER STEERING CONTROL VALVE)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44201H — Bearing(FOR POWER STEERING CONTROL VALVE UPPER) | ||||
| 90363-19005 |
Bearing(FOR POWER STEERING CONTROL VALVE UPPER)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 90363-19007 |
Bearing(FOR POWER STEERING CONTROL VALVE UPPER)
1997-12 → 1999-07
ended
|
EL50 RHD | — | |
| 90365-19001 |
Bearing(FOR POWER STEERING CONTROL VALVE UPPER)
1994-09 → 1997-12
ended
|
EL50 RHD | — | |
| 44201P — Bearing(FOR POWER STEERING CONTROL VALVE LOWER) | ||||
| 90363-12012 |
Bearing(FOR POWER STEERING CONTROL VALVE LOWER)
1994-09 → —
|
EL5# LHD | — | |
| 44201S — Ring, Snap(FOR POWER STEERING CONTROL VALVE) | ||||
| 90521-41005 |
Ring, Snap(FOR POWER STEERING CONTROL VALVE)
1994-09 → —
|
EL5# LHD | — | |
| 44203 — Housing Sub-assy, Power Steering Rack | ||||
| 44203-10050 |
Housing Sub-assy, Power Steering Rack
1994-09 → 1996-09
ended
|
EL53 | — | |
| 44203-16100 |
Housing Sub-assy, Power Steering Rack
1994-09 → 1996-07
ended
|
EL50 LHD | — | |
| 44203-16110 |
Housing Sub-assy, Power Steering Rack
1996-09 → —
|
EL53 | — | |
| 44203-16120 |
Housing Sub-assy, Power Steering Rack
1996-07 → 1996-08
ended
|
EL50 LHD | — | |
| 44203-16120 note |
Housing Sub-assy, Power Steering Rack
1996-03 → —
|
EL50 LHD GEN | — | |
| 44203-16120 |
Housing Sub-assy, Power Steering Rack
1996-08 → —
|
EL50 GCC | — | |
| 44204 — Rack Sub-assy, Power Steering | ||||
| 44204-10040 |
Rack Sub-assy, Power Steering
1995-08 → 1999-07
ended
|
EL50 RHD | — | |
| 44204-10050 |
Rack Sub-assy, Power Steering
1996-03 → 1996-07
ended
|
EL50 LHD | — | |
| 44204-10050 |
Rack Sub-assy, Power Steering
1996-07 → 1999-07
ended
|
EL5# LHD | — | |
| 44204-16050 |
Rack Sub-assy, Power Steering
1994-09 → 1996-03
ended
|
EL5# LHD | — | |
| 44204-16050 |
Rack Sub-assy, Power Steering
1996-03 → 1996-07
ended
|
EL53 | — | |
| 44204-16080 |
Rack Sub-assy, Power Steering
1994-09 → 1995-08
ended
|
EL50 RHD | — | |
| 44204A — Ring(FOR RACK STEERING PISTON) | ||||
| 90301-29005 note |
Ring(FOR RACK STEERING PISTON)
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 90301-31005 note |
Ring(FOR RACK STEERING PISTON)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 90562-34002 note |
Ring(FOR RACK STEERING PISTON)
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 90562-35002 note |
Ring(FOR RACK STEERING PISTON)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44206E — Seal, Oil, NO.1(FOR POWER STEERING CYLINDER TUBE) | ||||
| 90310-22003 |
Seal, Oil, NO.1(FOR POWER STEERING CYLINDER TUBE)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 90311-22015 |
Seal, Oil, NO.1(FOR POWER STEERING CYLINDER TUBE)
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 90311-22017 |
Seal, Oil, NO.1(FOR POWER STEERING CYLINDER TUBE)
1995-12 → 1999-07
ended
|
EL50 RHD | — | |
| 44206G — Spacer, NO.1(FOR POWER STEERING CYLINDER TUBE) | ||||
| 44263-16010 |
Spacer, NO.1(FOR POWER STEERING CYLINDER TUBE)
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 90560-22001 |
Spacer, NO.1(FOR POWER STEERING CYLINDER TUBE)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44253G — Seal, Oil, NO.2(FOR POWER STEERING RACK HOUSING) | ||||
| 90311-25017 |
Seal, Oil, NO.2(FOR POWER STEERING RACK HOUSING)
1994-09 → —
|
EL5# LHD | — | |
| 44275 — Stopper, Cylinder End | ||||
| 44275-10020 |
Stopper, Cylinder End
1995-12 → 1999-07
ended
|
EL50 RHD | — | |
| 44275-16020 |
Stopper, Cylinder End
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 44275-16030 |
Stopper, Cylinder End
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44275-16040 note |
Stopper, Cylinder End
1996-03 → 1996-10
ended
|
EL50 LHD GEN | — | |
| 44275-16040 note |
Stopper, Cylinder End
1996-10 → 1999-07
ended
|
EL53 | — | |
| 44275B — Seal, Oil(FOR CYLINDER END STOPPER) | ||||
| 90310-22003 |
Seal, Oil(FOR CYLINDER END STOPPER)
1994-09 → —
|
EL5# LHD | — | |
| 44275D — Bush(FOR CYLINDER END STOPPER) | ||||
| 44267-16010 note |
Bush(FOR CYLINDER END STOPPER)
1996-03 → 1996-10
ended
|
EL50 LHD GEN | — | |
| 44267-16010 note |
Bush(FOR CYLINDER END STOPPER)
1996-10 → 1997-12
ended
|
EL5# LHD GEN | — | |
| 44267-16010 note |
Bush(FOR CYLINDER END STOPPER)
1997-12 → —
|
EL53 | — | |
| 90386-22001 |
Bush(FOR CYLINDER END STOPPER)
1994-09 → —
|
EL5# LHD | — | |
| 44277 — Seat, Rack Guide | ||||
| 44277-10020 note |
Seat, Rack Guide
1994-09 → 1996-03
ended
|
EL50 LHD GEN | — | |
| 44277-10020 |
Seat, Rack Guide
1996-03 → 1996-10
ended
|
EL50 LHD | — | |
| 44277-10020 |
Seat, Rack Guide
1996-10 → —
|
EL5# LHD | — | |
| 44277-16040 |
Seat, Rack Guide
1994-09 → 1996-03
ended
|
EL5# LHD | — | |
| 44277-16040 note |
Seat, Rack Guide
1994-09 → 1996-03
ended
|
EL50 LHD | — | |
| 44277-16040 |
Seat, Rack Guide
1996-03 → 1996-10
ended
|
EL53 | — | |
| 44283 — Cap, Rack Housing | ||||
| 44283-16010 |
Cap, Rack Housing
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 44283-16020 |
Cap, Rack Housing
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44418A — Tube, Steering Right Turn Pressure | ||||
| 44418-10020 |
Tube, Steering Right Turn Pressure
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 44418-10030 |
Tube, Steering Right Turn Pressure
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44418B — Seat, Union(FOR STEERING TURN PRESSURE TUBE) | ||||
| 90410-04002 |
Seat, Union(FOR STEERING TURN PRESSURE TUBE)
1994-09 → —
|
EL5# LHD | — | |
| 44419A — Tube, Steering Left Turn Pressure | ||||
| 44419-10020 |
Tube, Steering Left Turn Pressure
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 44419-10030 |
Tube, Steering Left Turn Pressure
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 44523H — Spring(FOR POWER STEERING RACK GUIDE) | ||||
| 90501-20041 |
Spring(FOR POWER STEERING RACK GUIDE)
1996-07 → 1996-10
ended
|
EL50 LHD | — | |
| 90501-20041 |
Spring(FOR POWER STEERING RACK GUIDE)
1996-10 → 1999-07
ended
|
EL5# LHD | — | |
| 90501-23007 |
Spring(FOR POWER STEERING RACK GUIDE)
1996-03 → 1996-07
ended
|
EL50 LHD | — | |
| 90501-23075 |
Spring(FOR POWER STEERING RACK GUIDE)
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 90501-26063 note |
Spring(FOR POWER STEERING RACK GUIDE)
1996-07 → 1996-08
ended
|
EL50 LHD GEN | — | |
| 90501-26063 |
Spring(FOR POWER STEERING RACK GUIDE)
1996-03 → 1996-10
ended
|
EL53 | — | |
| 90501-26063 note |
Spring(FOR POWER STEERING RACK GUIDE)
1996-03 → 1996-10
ended
|
EL50 LHD GEN | — | |
| 90501-26063 |
Spring(FOR POWER STEERING RACK GUIDE)
1994-09 → 1996-03
ended
|
EL5# LHD | — | |
| 90501-26063 note |
Spring(FOR POWER STEERING RACK GUIDE)
1996-10 → 1999-07
ended
|
EL53 | — | |
| 90501-32031 |
Spring(FOR POWER STEERING RACK GUIDE)
1995-12 → 1999-07
ended
|
EL50 RHD | — | |
| 90502-32001 note |
Spring(FOR POWER STEERING RACK GUIDE)
1994-09 → 1996-03
ended
|
EL50 LHD GEN | — | |
| 45503 — End Sub-assy, Steering Rack | ||||
| 45503-19185 note |
End Sub-assy, Steering Rack
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 45503-19195 |
End Sub-assy, Steering Rack
1994-09 → 1999-07
ended
|
EL5# | — | |
| 45503B — Washer, Claw(FOR STEERING RACK END) | ||||
| 90214-12002 |
Washer, Claw(FOR STEERING RACK END)
1994-09 → —
|
EL5# | — | |
| 45523 — Guide, Rack(FOR STEERING GEAR) | ||||
| 45504-10020 note |
Guide, Rack(FOR STEERING GEAR)
1996-02 → 1999-07
ended
|
EL5# | — | |
| 45504-16050 note |
Guide, Rack(FOR STEERING GEAR)
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 45504-16060 note |
Guide, Rack(FOR STEERING GEAR)
1995-12 → 1999-07
ended
|
EL50 RHD | — | |
| 45523-10040 note |
Guide, Rack(FOR STEERING GEAR)
1994-09 → 1995-08
ended
|
EL5# | — | |
| 45523-10041 note |
Guide, Rack(FOR STEERING GEAR)
1995-08 → 1996-02
ended
|
EL5# | — | |
| 45523-10080 note |
Guide, Rack(FOR STEERING GEAR)
1996-03 → 1996-10
ended
|
EL53 | — | |
| 45523-10080 note |
Guide, Rack(FOR STEERING GEAR)
1994-09 → 1996-03
ended
|
EL5# LHD | — | |
| 45523-10090 note |
Guide, Rack(FOR STEERING GEAR)
1994-09 → 1996-03
ended
|
EL50 LHD GEN | — | |
| 45523-10090 note |
Guide, Rack(FOR STEERING GEAR)
1996-03 → 1996-10
ended
|
EL50 LHD | — | |
| 45523-10090 note |
Guide, Rack(FOR STEERING GEAR)
1996-10 → 1999-07
ended
|
EL5# LHD | — | |
| 45524 — Cap, Steering Rack Guide Spring | ||||
| 45524-10040 note |
Cap, Steering Rack Guide Spring
1994-09 → 1996-03
ended
|
EL5# LHD | — | |
| 45524-10040 note |
Cap, Steering Rack Guide Spring
1996-03 → 1996-07
ended
|
EL5# LHD | — | |
| 45524-10040 |
Cap, Steering Rack Guide Spring
1996-07 → 1996-10
ended
|
EL53 | — | |
| 45524-16040 note |
Cap, Steering Rack Guide Spring
1994-09 → 1996-02
ended
|
EL5# | — | |
| 45524-16050 |
Cap, Steering Rack Guide Spring
1995-12 → 1999-07
ended
|
EL50 RHD | — | |
| 45524-16060 |
Cap, Steering Rack Guide Spring
1996-03 → 1996-07
ended
|
EL5# LHD | — | |
| 45524-16060 |
Cap, Steering Rack Guide Spring
1996-07 → 1996-10
ended
|
EL50 LHD | — | |
| 45524-16060 |
Cap, Steering Rack Guide Spring
1996-10 → 1999-07
ended
|
EL5# LHD | — | |
| 45524-17020 note |
Cap, Steering Rack Guide Spring
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 45524A — Nut(FOR STEERING RACK GUIDE SPRING CAP) | ||||
| 90179-30002 |
Nut(FOR STEERING RACK GUIDE SPRING CAP)
1996-02 → 1999-07
ended
|
EL50 RHD | — | |
| 90179-33003 |
Nut(FOR STEERING RACK GUIDE SPRING CAP)
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 45535 — Boot, Steering Rack, NO.1 | ||||
| 45535-10021 note |
Boot, Steering Rack, NO.1
1994-09 → 1999-07
ended
|
EL5# | — | |
| 45535-10060 note |
Boot, Steering Rack, NO.1
1995-12 → 1999-07
ended
|
EL50 RHD | — | |
| 45535-16010 note |
Boot, Steering Rack, NO.1
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 45535-16030 note |
Boot, Steering Rack, NO.1
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 45535B — Clip(FOR STEERING RACK BOOT) | ||||
| 90467-17021 note |
Clip(FOR STEERING RACK BOOT)
1994-09 → 1999-07
ended
|
EL50 RHD | — | |
| 90467-18003 |
Clip(FOR STEERING RACK BOOT)
1994-09 → 1999-07
ended
|
EL5# | — | |
| 45535D — Clamp(FOR STEERING RACK BOOT NO.1) | ||||
| 90460-49002 note |
Clamp(FOR STEERING RACK BOOT NO.1)
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 90460-56002 note |
Clamp(FOR STEERING RACK BOOT NO.1)
1994-09 → —
|
EL5# LHD | — | |
| 90461-08718 note |
Clamp(FOR STEERING RACK BOOT NO.1)
1995-12 → —
|
EL50 RHD | — | |
| 90461-10273 note |
Clamp(FOR STEERING RACK BOOT NO.1)
1994-09 → —
|
EL5# | — | |
| 45536 — Boot, Steering Rack, NO.2 | ||||
| 45535-10060 note |
Boot, Steering Rack, NO.2
1995-12 → 1999-07
ended
|
EL50 RHD | — | |
| 45535-16010 note |
Boot, Steering Rack, NO.2
1994-09 → 1999-07
ended
|
EL5# LHD | — | |
| 45535-16030 note |
Boot, Steering Rack, NO.2
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 45536-10060 note |
Boot, Steering Rack, NO.2
1994-09 → 1999-07
ended
|
EL5# | — | |
| 45536A — Clamp(FOR STEERING RACK BOOT NO.2) | ||||
| 90460-49002 note |
Clamp(FOR STEERING RACK BOOT NO.2)
1994-09 → 1995-12
ended
|
EL50 RHD | — | |
| 90460-56002 note |
Clamp(FOR STEERING RACK BOOT NO.2)
1994-09 → —
|
EL5# LHD | — | |
| 90461-08718 note |
Clamp(FOR STEERING RACK BOOT NO.2)
1995-12 → —
|
EL50 RHD | — | |
| 90461-10646 note |
Clamp(FOR STEERING RACK BOOT NO.2)
1994-09 → —
|
EL5# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
