Toyota Tercel
1994-09 → 1999-07 · chassis EL50,53 · catalogue 141350 · General
Discontinued model
Data version 2000-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 44610 — Booster Assy, Brake | ||||
| 44610-16540 |
Booster Assy, Brake
1996-05 → 1997-12
ended
|
EL50 RHD | — | |
| 44610-16570 |
Booster Assy, Brake
1994-09 → 1996-05
ended
|
EL50 RHD | — | |
| 44610-16580 |
Booster Assy, Brake
1994-09 → —
|
EL5# LHD | — | |
| 44610-16660 |
Booster Assy, Brake
1997-12 → —
|
EL50 RHD | — | |
| 44730 — Valve Assy, Vacuum Check(FOR BRAKE) | ||||
| 44580-22030 |
Valve Assy, Vacuum Check(FOR BRAKE)
1994-09 → —
|
EL53 | — | |
| 44730-10010 |
Valve Assy, Vacuum Check(FOR BRAKE)
1994-09 → —
|
EL50 LHD | — | |
| 44730-24010 |
Valve Assy, Vacuum Check(FOR BRAKE)
1994-09 → —
|
EL50 RHD | — | |
| 44730C — Clip(FOR VACUUM HOSE) | ||||
| 90467-16002 |
Clip(FOR VACUUM HOSE)
1994-09 → 1995-12
ended
|
EL53;EL50 RHD | — | |
| 90467-16002 |
Clip(FOR VACUUM HOSE)
1994-09 → —
|
EL50 LHD | — | |
| 90467-16002 note |
Clip(FOR VACUUM HOSE)
1995-12 → —
|
EL53 | — | |
| 90467-16002 |
Clip(FOR VACUUM HOSE)
1995-12 → —
|
EL50 RHD | — | |
| 90467-16024 note |
Clip(FOR VACUUM HOSE)
1995-12 → —
|
EL53 | — | |
| 44730F — Union, Vacuum Hose(FOR MANIFOLD SIDE) | ||||
| 90404-51034 |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1994-09 → —
|
EL50 | — | |
| 90406-09006 |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1995-08 → —
|
EL53 | — | |
| 90407-51002 |
Union, Vacuum Hose(FOR MANIFOLD SIDE)
1994-09 → 1995-08
ended
|
EL53 | — | |
| 44758 — Bracket, Vacuum Check Valve | ||||
| 44758-16080 |
Bracket, Vacuum Check Valve
1994-09 → —
|
EL50 LHD | — | |
| 44763B — Tube, Tube Connector TO Tube Connector | ||||
| 44763-16030 |
Tube, Tube Connector TO Tube Connector
1994-09 → 1995-08
ended
|
EL53 | — | |
| 44763-16040 |
Tube, Tube Connector TO Tube Connector
1994-09 → 1997-12
ended
|
EL50 RHD | — | |
| 44763-16050 |
Tube, Tube Connector TO Tube Connector
1995-08 → —
|
EL53 | — | |
| 44763-16080 |
Tube, Tube Connector TO Tube Connector
1997-12 → —
|
EL50 RHD | — | |
| 44772B — Hose, Check Valve TO Brake Booster | ||||
| 44772-16110 |
Hose, Check Valve TO Brake Booster
1994-09 → 1995-08
ended
|
EL53 | — | |
| 44772-16120 |
Hose, Check Valve TO Brake Booster
1994-09 → —
|
EL50 LHD | — | |
| 44772-16130 |
Hose, Check Valve TO Brake Booster
1994-09 → 1997-12
ended
|
EL50 RHD | — | |
| 44772-16150 |
Hose, Check Valve TO Brake Booster
1995-08 → —
|
EL53 | — | |
| 44772-16160 |
Hose, Check Valve TO Brake Booster
1997-12 → —
|
EL50 RHD | — | |
| 44773F — Hose, Union TO Check Valve | ||||
| 44773-16120 |
Hose, Union TO Check Valve
1994-09 → 1995-08
ended
|
EL53 | — | |
| 44773-16130 |
Hose, Union TO Check Valve
1994-09 → —
|
EL50 LHD | — | |
| 44773-16140 |
Hose, Union TO Check Valve
1994-09 → —
|
EL50 RHD | — | |
| 44773-16160 |
Hose, Union TO Check Valve
1995-08 → —
|
EL53 | — | |
| 44785 — Gasket, Brake Booster | ||||
| 44785-10020 |
Gasket, Brake Booster
1994-09 → 1995-08
ended
|
EL5# | — | |
| 44785-16020 |
Gasket, Brake Booster
1995-08 → —
|
EL5# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
