Toyota Tercel
1994-09 → 1999-07 · chassis EL50,53 · catalogue 141350 · General
Discontinued model
Data version 2000-02
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 50540 — DO0R Assy, Airbag Passenger | ||||
| 55431-16010-B0 note |
DO0R Assy, Airbag Passenger
1994-09 → 1996-08
ended
|
EL5# LHD | — | |
| 55431-16010-B1 note |
DO0R Assy, Airbag Passenger
1996-08 → —
|
EL5# LHD | — | |
| 55431-16010-E0 note |
DO0R Assy, Airbag Passenger
1994-09 → —
|
EL5# LHD | — | |
| 55419A — Cushion, Instrument Cluster Finish Panel | ||||
| 55419-14020 |
Cushion, Instrument Cluster Finish Panel
1994-09 → 1995-02
ended
|
EL5# | — | |
| 55441C — Box, Instrument Panel Coin | ||||
| 55441-16110-B0 note |
Box, Instrument Panel Coin
1994-09 → 1996-08
ended
|
EL5# LHD | — | |
| 55441-16110-B1 note |
Box, Instrument Panel Coin
1996-08 → —
|
EL5# LHD | — | |
| 55441-16110-E0 note |
Box, Instrument Panel Coin
1994-09 → —
|
EL5# LHD | — | |
| 55521C — Cover, Stereo Opening | ||||
| 55521-16030 |
Cover, Stereo Opening
1994-09 → —
|
EL5# | — | |
| 55522B — Cover, Radio Tuner Opening | ||||
| 55522-20070 |
Cover, Radio Tuner Opening
1994-09 → —
|
EL5# | — | |
| 55522E — Cover, Cup Holder Opening | ||||
| 55522-16030 |
Cover, Cup Holder Opening
1994-09 → 1997-12
ended
|
EL5# | — | |
| 55522-16040-C0 note |
Cover, Cup Holder Opening
1997-12 → —
|
EL5# | — | |
| 55522-16040-E0 note |
Cover, Cup Holder Opening
1997-12 → —
|
EL5# | — | |
| 55533 — Cover, Auto Clock Hole | ||||
| 55533-16040-B0 note |
Cover, Auto Clock Hole
1994-09 → 1996-08
ended
|
EL50 RHD | — | |
| 55533-16040-B1 note |
Cover, Auto Clock Hole
1996-08 → —
|
EL50 RHD | — | |
| 55533-16040-E0 note |
Cover, Auto Clock Hole
1994-09 → —
|
EL50 RHD | — | |
| 55533-16050-B0 note |
Cover, Auto Clock Hole
1994-09 → 1996-08
ended
|
EL5# LHD | — | |
| 55533-16050-B1 note |
Cover, Auto Clock Hole
1996-08 → —
|
EL5# LHD | — | |
| 55533-16050-E0 note |
Cover, Auto Clock Hole
1994-09 → —
|
EL5# LHD | — | |
| 55539B — Cover, Spare Switch Hole, NO.2 | ||||
| 55539-16040-B1 note |
Cover, Spare Switch Hole, NO.2
1997-12 → —
|
EL50 RHD | — | |
| 55539-16040-E0 note |
Cover, Spare Switch Hole, NO.2
1997-12 → —
|
EL50 RHD | — | |
| 55539-32010-C0 note |
Cover, Spare Switch Hole, NO.2
1994-09 → 1996-08
ended
|
EL5# | — | |
| 55539C — Cover, Spare Switch Hole | ||||
| 55539-16040-B0 note |
Cover, Spare Switch Hole
1994-09 → 1996-08
ended
|
EL50 RHD | — | |
| 55539-16040-B1 note |
Cover, Spare Switch Hole
1996-08 → 1997-12
ended
|
EL50 RHD | — | |
| 55539-16040-E0 note |
Cover, Spare Switch Hole
1994-09 → 1997-12
ended
|
EL50 RHD | — | |
| 55539-32010-E4 note |
Cover, Spare Switch Hole
1997-12 → —
|
EL5# | — | |
| 55539E — Cover, Spare Switch Hole | ||||
| 55539-16050-B0 note |
Cover, Spare Switch Hole
1994-09 → 1996-08
ended
|
EL5# LHD | — | |
| 55539-16050-B1 note |
Cover, Spare Switch Hole
1996-08 → —
|
EL5# LHD | — | |
| 55539-16050-E0 note |
Cover, Spare Switch Hole
1994-09 → —
|
EL5# LHD | — | |
| 55545 — Cover, Fuse Box Opening | ||||
| 55545-16170-B0 note |
Cover, Fuse Box Opening
1994-09 → 1996-08
ended
|
EL50 RHD | — | |
| 55545-16170-E0 note |
Cover, Fuse Box Opening
1994-09 → 1996-08
ended
|
EL50 RHD | — | |
| 55545-16171-B1 note |
Cover, Fuse Box Opening
1996-08 → 1997-12
ended
|
EL50 RHD | — | |
| 55545-16171-E0 note |
Cover, Fuse Box Opening
1996-08 → 1997-12
ended
|
EL50 RHD | — | |
| 55545-16180-B0 note |
Cover, Fuse Box Opening
1994-09 → 1996-08
ended
|
EL5# LHD | — | |
| 55545-16180-B1 note |
Cover, Fuse Box Opening
1996-08 → 1997-12
ended
|
EL5# LHD | — | |
| 55545-16180-E0 note |
Cover, Fuse Box Opening
1994-09 → 1997-12
ended
|
EL5# LHD | — | |
| 55545-16230-B0 note |
Cover, Fuse Box Opening
1997-12 → —
|
EL5# | — | |
| 55545-16230-B1 note |
Cover, Fuse Box Opening
1997-12 → —
|
EL5# GEN | — | |
| 55545-16230-E0 note |
Cover, Fuse Box Opening
1997-12 → —
|
EL5# | — | |
| 55545-16230-E1 note |
Cover, Fuse Box Opening
1997-12 → —
|
EL5# GEN | — | |
| 55560A — Lock Assy, Glove Compartment Door | ||||
| 55560-16060-B0 note |
Lock Assy, Glove Compartment Door
1994-09 → 1996-08
ended
|
EL5# LHD | — | |
| 55560-16060-B1 note |
Lock Assy, Glove Compartment Door
1996-08 → —
|
EL5# LHD | — | |
| 55560-16060-E0 note |
Lock Assy, Glove Compartment Door
1994-09 → —
|
EL5# LHD | — | |
| 55950A — Nozzle Assy, Defroster | ||||
| 55950-16060 |
Nozzle Assy, Defroster
1994-09 → —
|
EL50 RHD | — | |
| 55950-16070 |
Nozzle Assy, Defroster
1994-09 → —
|
EL5# LHD | — | |
| 55967A — Nozzle, Defroster, Lower | ||||
| 55967-16040 |
Nozzle, Defroster, Lower
1994-09 → —
|
EL5# | — | |
| 73970A — Airbag Assy, Instrument Panel Passenger | ||||
| 73970-16040-B0 note |
Airbag Assy, Instrument Panel Passenger
1997-12 → —
|
EL50 GCC | — | |
| 73970-16040-E0 note |
Airbag Assy, Instrument Panel Passenger
1997-12 → —
|
EL50 GCC | — | |
| 74598B — Label, Passenger Airbag Caution | ||||
| 74598-20010 |
Label, Passenger Airbag Caution
1997-12 → —
|
EL50 GCC | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
